MG60 Fat_190

Bafang G60 Standard Wind (8.2 rpm/V) Rear Hub Motor for 190-195mm Fatbike Dropouts. Terminated with 9-pin Waterproof Higo Z910 Motor Plug
Availability: In stock

This is an extra wide version of the Bafang G60 rear geared hub motor that fits Fatbike installations with 190-195mm dropout lengths. This is the G60.500W model which is almost as powerful as the eZee hubs with plenty of torque for offroad riding. It uses a cassette freehub rather than a screw on freewheel for modern derailleur systems and has a disc mount as well. The hub shell includes an internal 6-pole speedeometer sensor so it can use a CA-DP device and not require an external speedo pickup. This motor is wound with a standard 8.2 RPM/V typically suited for 26" wheels.

Uses 9-pin overmolded Higo Z910 waterproof connector for the motor phase, hall, and speedometer wire that is compatible with our 20A Grinfineon and Baserunner_Z9 controllers.

More Information
Country of Manufacture China
Actual Weight (kg) 4.2
Motor MFG Bafang
Motor Power Range (Watts) 500-1000
Motor KV (RPM / V) 8.2
Phase Resistance (Ohm) 0.080
Disk Brake Compatible Yes
Connector(s) Z910
Axle Length (O.L.D.) 190
Axle Threads M12 x 1.25mm
Spoke Holes 36 Hole
Motor Type Geared
Flange Spoke Diameter (mm) 145
Magnetic Pole Pairs (Phaserunner) 50
Speedo Poles (for CA) 6
Hysteresis Losses (N-m) 0.58
Eddie Losses (N-m / rad/sec) 0.022
Motor Inductance (H) 0.00020
