Grin All-Axle Ready-To-Roll Kit

Ready-to-Roll Front All-Axle Motor Kit, with Downtube Battery, Baserunner Controller, V3 Cycle Analyst and PAS/Torque Sensor Options. Supports Quick Release and Thru Axle Suspension Forks.

Full Product Information Page



From USD$985.00

To USD$3,365.00

In stock

SKU
KIT-Grin_RTR
Add to Wish List Add to Compare
Customize Grin All-Axle Ready-To-Roll Kit
Grin Hub Torque Arm Kit
L10 Extension Cable (60cm)
CA3-WPx
CA3_MFSwitch for CA3-WPx

* Required Fields

Your Customization
Grin All-Axle Motor Conversion Kit, Black Anodized
Grin All-Axle Ready-To-Roll Kit

In stock

USD$985.00

Actual cruising speed/perfomance under any loading conditions is well modeled in our simulator.
Launch Motor Simulator with Grin All-Axle Ready-To-Roll Kit

Summary

    Grin All-Axle front hub motor kit with downtube battery and integrated Baserunner_L10 motor controller. Universal front hub motor works with virtually all fork standards, from quick release to 12, 15, and 20mm thru axles to single side mounts as well. Motor is just over 4kg, and and feature 0.35mm laminations, a Statorade injection port, and the L10 connector with internal thermistor. Kit includes various PAS or Torque Sensor Options for the V3 Cycle Analyst

    Specifications
    GrinHub_SL
    Actual Weight (kg)
    4.05
    Motor MFG
    Grin Tech
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    7.5
    Phase Resistance (Ohm)
    0.268
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Spoke Holes
    32 Hole
    Motor Type
    Direct Drive
    Flange Spoke Diameter (mm)
    214
    Magnetic Pole Pairs (Phaserunner)
    23
    Hysteresis Losses (N-m)
    0.6
    Eddie Losses (N-m / rad/sec)
    0.005
    GrinHub_SL_Bk
    Actual Weight (kg)
    4.05
    Motor MFG
    Grin Tech
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    7.5
    Phase Resistance (Ohm)
    0.268
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Spoke Holes
    32 Hole
    Motor Type
    Direct Drive
    Flange Spoke Diameter (mm)
    214
    Magnetic Pole Pairs (Phaserunner)
    23
    Hysteresis Losses (N-m)
    0.6
    Eddie Losses (N-m / rad/sec)
    0.005
    GrinHub_Std
    Actual Weight (kg)
    4.05
    Motor MFG
    Grin Tech
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    10.0
    Phase Resistance (Ohm)
    0.145
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Spoke Holes
    32 Hole
    Motor Type
    Direct Drive
    Flange Spoke Diameter (mm)
    214
    Magnetic Pole Pairs (Phaserunner)
    23
    Hysteresis Losses (N-m)
    0.45
    Eddie Losses (N-m / rad/sec)
    0.005
    GrinHub_Std_Bk
    Actual Weight (kg)
    4.05
    Motor MFG
    Grin Tech
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    10.0
    Phase Resistance (Ohm)
    0.145
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Spoke Holes
    32 Hole
    Motor Type
    Direct Drive
    Flange Spoke Diameter (mm)
    214
    Magnetic Pole Pairs (Phaserunner)
    23
    Hysteresis Losses (N-m)
    0.45
    Eddie Losses (N-m / rad/sec)
    0.005
    GrinHub_Fst
    Actual Weight (kg)
    4.05
    Motor MFG
    Grin Tech
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    12.0
    Phase Resistance (Ohm)
    0.10
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Spoke Holes
    32 Hole
    Motor Type
    Direct Drive
    Flange Spoke Diameter (mm)
    214
    Magnetic Pole Pairs (Phaserunner)
    23
    Hysteresis Losses (N-m)
    0.45
    Eddie Losses (N-m / rad/sec)
    0.005
    GrinHub_Fst_Bk
    Actual Weight (kg)
    4.05
    Motor MFG
    Grin Tech
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    12.0
    Phase Resistance (Ohm)
    0.10
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Spoke Holes
    32 Hole
    Motor Type
    Direct Drive
    Flange Spoke Diameter (mm)
    214
    Magnetic Pole Pairs (Phaserunner)
    23
    Hysteresis Losses (N-m)
    0.45
    Eddie Losses (N-m / rad/sec)
    0.005
    Rim16_ZAC19_32H
    Actual Weight (kg)
    0.64
    Rim Width (mm)
    25
    Spoke Holes
    32 Hole
    Nominal Rim Size
    16" (ISO 349)
    Rim ERD
    332
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim20_ZAC19_32H
    Actual Weight (kg)
    0.42
    Rim Width (mm)
    24
    Spoke Holes
    32 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim ERD
    394
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim20_DM30_32H
    Rim Width (mm)
    30
    Spoke Holes
    32 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim Brake Compatible
    Yes
    Rim20_Fat_32H
    Actual Weight (kg)
    0.82
    Rim Width (mm)
    65
    Spoke Holes
    32 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim ERD
    384
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim24_Alex_32H
    Actual Weight (kg)
    0.64
    Rim Width (mm)
    32
    Spoke Holes
    32 Hole
    Nominal Rim Size
    24" (ISO 507)
    Rim ERD
    494
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim24_Fat_32H
    Actual Weight (kg)
    1.02
    Rim Width (mm)
    65
    Spoke Holes
    32 Hole
    Nominal Rim Size
    24" (ISO 507)
    Rim ERD
    485
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim26_DM18_32H
    Actual Weight (kg)
    0.53
    Rim Width (mm)
    24
    Spoke Holes
    32 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    543
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim26_Alex_32H
    Actual Weight (kg)
    0.76
    Rim Width (mm)
    32
    Spoke Holes
    32 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    544
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim26_Fat_32H
    Actual Weight (kg)
    1.06
    Rim Width (mm)
    65
    Spoke Holes
    32 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    537
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim275_DM30_32H
    Actual Weight (kg)
    0.76
    Rim Width (mm)
    30
    Spoke Holes
    32 Hole
    Nominal Rim Size
    650B (ISO 584)
    Rim ERD
    565
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim700_DM18_32H
    Actual Weight (kg)
    0.6
    Rim Width (mm)
    24
    Spoke Holes
    32 Hole
    Nominal Rim Size
    700C (ISO 622)
    Rim ERD
    607
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    V6 Baserunner_L10
    Manufacturer
    Grin
    Dimensions (L x W x H, mm)
    90 x 55 x 15
    Actual Weight (kg)
    0.18
    Max Regen Voltage (V)
    60
    Max Battery Amps (A)
    35
    Max Phase Amps (A)
    80
    Battery Range (V)
    20-60
    Connector(s)
    HiGo 0812(WP8), Higo Signal C, Mains D1109
    Phaserunner L10 Silver
    Manufacturer
    Grin
    Dimensions (L x W x H, mm)
    99 x 40 x 34
    Actual Weight (kg)
    0.26
    Max Regen Voltage (V)
    Programmable: 20-90V
    Max Battery Amps (A)
    40
    Max Phase Amps (A)
    80
    Battery Range (V)
    30-90
    Connector(s)
    Anderson, HiGo 0812(WP8), L1019, TRRS, XT60, HiGo MiniB, Mains D1109
    Phaserunner L10 Black
    Manufacturer
    Grin
    Dimensions (L x W x H, mm)
    99 x 40 x 34
    Actual Weight (kg)
    0.26
    Max Regen Voltage (V)
    Programmable: 20-90V
    Max Battery Amps (A)
    40
    Max Phase Amps (A)
    90
    Battery Range (V)
    30-90
    Connector(s)
    Anderson, HiGo 0812(WP8), L1019, TRRS, XT60, HiGo MiniB, Mains D1109
    36V 10Ah Bottle Battery
    Actual Weight (kg)
    2.2
    Dimensions (L x W x H, mm)
    295x78x78
    Mounting Type
    Frame Mount
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    9.8
    Watt-hours at 1C Discharge
    345
    Cell Type
    Panasonic GA 10S x 4P
    Internal Resistance (Ohms)
    0.19
    Connector(s)
    Anderson, ST3
    36V 14Ah Bottle Battery
    Actual Weight (kg)
    2.7
    Dimensions (L x W x H, mm)
    363x78x78
    Mounting Type
    Frame Mount
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    13.3
    Watt-hours at 1C Discharge
    460
    Cell Type
    Panasonic GA 10S x 4P
    Internal Resistance (Ohms)
    0.160
    Connector(s)
    Anderson, ST3
    36V 14.5Ah Downtube Battery
    Actual Weight (kg)
    3.15
    Dimensions (L x W x H, mm)
    365x100x105
    Mounting Type
    Frame Mount
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    14.5
    Cell Type
    NCR21700A 10S x 3P
    Connector(s)
    Anderson, DT_4pinSpade, ST3
    36V 15.5Ah eZee Flat Pack
    Manufacturer
    eZee
    Actual Weight (kg)
    3.5
    Dimensions (L x W x H, mm)
    348x141x59
    Mounting Type
    Rear Rack
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42
    Capacity (Amp-Hours)
    15.5
    Cell Type
    LG 18650 MH1, 10S x 5P
    Internal Resistance (Ohms)
    0
    Connector(s)
    Anderson, XLR
    36V 20Ah Downtube Battery
    Actual Weight (kg)
    4.02
    Dimensions (L x W x H, mm)
    365x95x100
    Mounting Type
    Frame Mount
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    19.25
    Cell Type
    Panasonic NCR21700A 10S x 4P
    Connector(s)
    Anderson, DT_4pinSpade, ST3
    36V 22Ah eZee Flat Pack
    Manufacturer
    eZee
    Actual Weight (kg)
    4.4
    Dimensions (L x W x H, mm)
    348x141x59
    Mounting Type
    Rear Rack
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42
    Capacity (Amp-Hours)
    21.5
    Cell Type
    LG 18650 MH1, 10S x 7P
    Internal Resistance (Ohms)
    0
    Connector(s)
    Anderson, XLR
    36V 24Ah Downtube Battery
    Actual Weight (kg)
    4.8
    Dimensions (L x W x H, mm)
    365x95x124
    Mounting Type
    Frame Mount, Rear Rack
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42
    Capacity (Amp-Hours)
    24
    Cell Type
    Panasonic 21700A 10S x 5P
    Internal Resistance (Ohms)
    0.80
    Connector(s)
    Anderson, ST3
    48V 10Ah Bottle Battery
    Actual Weight (kg)
    2.7
    Dimensions (L x W x H, mm)
    363x78x78
    Mounting Type
    Frame Mount
    Nominal Voltage
    48 Volt (13s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    9.9
    Watt-hours at 1C Discharge
    450
    Cell Type
    Panasonic GA 13S x 3P
    Internal Resistance (Ohms)
    0.170
    Connector(s)
    Anderson, ST3
    48V 14.5Ah Downtube Battery
    Actual Weight (kg)
    4.0
    Dimensions (L x W x H, mm)
    365x100x105
    Mounting Type
    Frame Mount
    Nominal Voltage
    48 Volt (13s)
    Full Charge Voltage
    54.5
    Cell Type
    NCR 21700 A 13S x 3P
    Connector(s)
    Anderson, DT_4pinSpade
    48V 15.5Ah eZee Flat Pack
    Manufacturer
    eZee
    Actual Weight (kg)
    7.8
    Dimensions (L x W x H, mm)
    348x141x59
    Mounting Type
    Rear Rack
    Nominal Voltage
    48 Volt (13s)
    Full Charge Voltage
    54.5
    Capacity (Amp-Hours)
    15.5
    Cell Type
    LG 18650 MH1, 13S x 5P
    Internal Resistance (Ohms)
    0.156
    Connector(s)
    Anderson, XLR
    48V 17Ah eZee Flat Pack
    Manufacturer
    eZee
    Actual Weight (kg)
    4.3
    Dimensions (L x W x H, mm)
    348x141x59
    Mounting Type
    Rear Rack
    Nominal Voltage
    48 Volt (13s)
    Full Charge Voltage
    54.5
    Capacity (Amp-Hours)
    16.5
    Cell Type
    Samsung 35E 13S x 5P
    Internal Resistance (Ohms)
    0.120
    Connector(s)
    Anderson, XLR
    48V 19Ah Downtube Battery
    Actual Weight (kg)
    4.9
    Dimensions (L x W x H, mm)
    365x100x124
    Mounting Type
    Frame Mount
    Nominal Voltage
    48 Volt (13s)
    Full Charge Voltage
    54.6
    Capacity (Amp-Hours)
    19
    Cell Type
    Panasonic 27100 A 13S x 4P
    Internal Resistance (Ohms)
    0.12
    Connector(s)
    Anderson, ST3
    52V 15Ah Downtube Battery
    Actual Weight (kg)
    4.3
    Dimensions (L x W x H, mm)
    380x95x100
    Mounting Type
    Frame Mount
    Nominal Voltage
    52 Volt (14s)
    Full Charge Voltage
    58.8
    Capacity (Amp-Hours)
    14.5
    Cell Type
    NCR21700A 14S x 3P
    Connector(s)
    Anderson, ST3
    52V 20Ah Downtube Battery
    Actual Weight (kg)
    5.38
    Dimensions (L x W x H, mm)
    370x89x137
    Mounting Type
    Frame Mount
    Nominal Voltage
    52 Volt (14s)
    Full Charge Voltage
    58.8
    Capacity (Amp-Hours)
    19.8
    Cell Type
    Panasonic GA 14S x 6P
    Internal Resistance (Ohms)
    0.12
    Connector(s)
    Anderson, ST3
    52V 23Ah Triangle Battery
    Actual Weight (kg)
    6.08
    Mounting Type
    Frame Mount
    Nominal Voltage
    52 Volt (14s)
    Full Charge Voltage
    58.8
    Capacity (Amp-Hours)
    23.5
    Cell Type
    Samsung 35E cells 14S x 7P
    Connector(s)
    Anderson, ST3, XT-90S
    36V 2A ST3 Charger
    Actual Weight (kg)
    0.36
    Connector(s)
    ST3
    36V 4A ST3 Charger 220VAC
    Actual Weight (kg)
    0.58
    Connector(s)
    ST3
    36V 2A XLR Charger
    Actual Weight (kg)
    0.5
    Connector(s)
    XLR
    36V 4A XLR Charger
    Actual Weight (kg)
    0.98
    Connector(s)
    XLR
    48V 2A ST3 Charger
    Actual Weight (kg)
    0.48
    Connector(s)
    ST3
    48V 4A ST3 Charger
    Actual Weight (kg)
    0.48
    Connector(s)
    ST3
    48V 2A XLR Charger
    Actual Weight (kg)
    0.5
    Connector(s)
    XLR
    52V 2A ST3 Charger
    Actual Weight (kg)
    .36
    Dimensions (L x W x H, mm)
    170x72x34
    Connector(s)
    ST3
    52V 2A XLR Charger
    Actual Weight (kg)
    0.5
    Dimensions (L x W x H, mm)
    170x72x34
    Connector(s)
    XLR
    52V 4A XLR Charger
    Actual Weight (kg)
    0.88
    Dimensions (L x W x H, mm)
    170x72x34
    Connector(s)
    XLR
    52V 4A ST-3 Charger 110-240
    Actual Weight (kg)
    0.84
    Connector(s)
    ST3
    Satiator Upgrade with ST3 Adapter
    Actual Weight (kg)
    1.06
    CA3-WPx
    Actual Weight (kg)
    0.3
    12 Pole PAS with Spindle Mounted Magdisc
    Manufacturer
    King Meter
    Actual Weight (kg)
    0.12
    PAS Poles
    12
    PAS Encoder Type
    2 Wire (Quadrature)
    12 Pole PAS with Chainring Mounted Magdisc
    PAS Poles
    12
    PAS Encoder Type
    2 Wire (Quadrature)
    24 Pole PAS (Short 90cm Cable)
    Actual Weight (kg)
    .06
    Connector(s)
    JST-SM
    PAS Poles
    24
    PAS Encoder Type
    2 Wire (Quadrature)
    24 Pole PAS (Long 120cm Cable)
    Actual Weight (kg)
    .06
    Connector(s)
    JST-SM
    PAS Poles
    24
    PAS Encoder Type
    2 Wire (Quadrature)
    Fischer AG Torque Sensing BB, 127mm
    Actual Weight (kg)
    0.3300
    Connector(s)
    JST-SM, HiGo MiniB
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    0.6
    ERider68-T17 BB with 4 Arm Spider
    Actual Weight (kg)
    1.06
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    ERider68-T17 BB with 5 Arm Spider
    Actual Weight (kg)
    1.06
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    ERider68-T17 BB with 52T Chainring
    Actual Weight (kg)
    1.3
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    ERider73-T17 BB with 4 Arm Spider
    Actual Weight (kg)
    1.06
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    ERider73-T17 BB with 5 Arm Spider
    Actual Weight (kg)
    1.06
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    ERider73-T17 BB with 52T Chainring
    Actual Weight (kg)
    1.3
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    Handlebar Phone Mount and Charger
    Actual Weight (kg)
    0.165
    Minimum Input Voltage (V)
    12
    Max Input Voltage (V)
    95
    Connector / Jack
    5.5 x 2.1mm DC Jack
    Output Voltage
    5V
    Output Current (A)
    2
    C7 Plus, 3W 80 Lux Ebike Light
    Actual Weight (kg)
    .088
    Light Source
    OSRAM
    Minimum Input Voltage (V)
    6
    Max Input Voltage (V)
    58
    Peak Input Power (Watts)
    3
    Connector / Jack
    DC5.5x2.1
    Roxim X4 Ebike Light
    Actual Weight (kg)
    0.16
    Light Source
    Cree XP-L
    Lumens Output
    400
    Minimum Input Voltage (V)
    6
    Max Input Voltage (V)
    85
    Peak Input Power (Watts)
    5.5
    Connector / Jack
    DC 5.5x2.1mm
    SPL-01 1900 Lumen Ebike Light
    Actual Weight (kg)
    0.12
    Light Source
    Multiple LEDs
    Lumens Output
    1900
    Turn-On Voltage (reduced power)
    8
    Minimum Input Voltage (V)
    12
    Max Input Voltage (V)
    60
    Peak Input Power (Watts)
    20
    Connector / Jack
    DC 5.5x2.1mm
    More Information
    Product Attachments
    Cycle Analyst Version 3.1 User Manual, Rev1.2 (2.46 MB)
    V1 Grin All-Axle Front Motor Dimensional Diagram (PDF) (96.05 kB)
    3D IGS File of Grin SS DIY Adapter (622.05 kB)
    3D IGS File of Grin Catrike Single Side Adapter (629.37 kB)
    3D IGS File of Grin Freecross Single Side Adapter (666.63 kB)
    3D IGS File of Grin Greenspeed Single Side Adapter (649.70 kB)
    3D IGS File of Grin ICE Single Side Adapter (666.63 kB)
    3D IGS File of Grin Terratrike Single Side Adapter (651.36 kB)
    3D PDF File of Grin Single Side Adapters (136.59 kB)
    Phaserunner User Manual V2 (1.45 MB)
    Phaserunner V3 Updates (538.75 kB)
    V1 Grin All-Axle Front Motor Dimensional Diagram (PDF) (96.05 kB)
    V1 Grin All-Axle Front Motor Dimensional Diagram (PDF) (96.05 kB)
    V1 Grin All-Axle Front Motor Dimensional Diagram (PDF) (96.05 kB)
    V2 Grin All-Axle Front Motor (3D IGS CAD) (25.89 MB)
    V1 Grin All-Axle Front Motor Dimensional Diagram (PDF) (96.05 kB)
    V1 Grin All-Axle Front Motor Dimensional Diagram (PDF) (96.05 kB)
    V1 Grin All-Axle Front Motor Dimensional Diagram (PDF) (96.05 kB)
    V4 Baserunner Manual (2.14 MB)
    Phaserunner Dimensional Diagram (111.82 kB)
    Phaserunner User Manual V2 (1.45 MB)
    Phaserunner V3 Updates (538.75 kB)
    V6 Phaserunner Release Note (236.61 kB)
    Phaserunner V6 Manual (1.97 MB)
    V6 Phaserunner Release Note (236.61 kB)
    Phaserunner V6 Manual (1.97 MB)
    Phaserunner Dimensional Diagram (111.82 kB)
    Battery_Care_Guide (162.81 kB)
    Battery Care Guide - Japanese(translated by a happy customer in Japan) (117.72 kB)
    Battery_Care_Guide (162.81 kB)
    Battery Care Guide - Japanese(translated by a happy customer in Japan) (117.72 kB)
    Battery_Care_Guide (162.81 kB)
    Battery Care Guide - Japanese(translated by a happy customer in Japan) (117.72 kB)
    eZee 36V 15Ah Lithium Battery Manual (395.21 kB)
    Battery_Care_Guide (162.81 kB)
    Battery_Care_Guide (162.81 kB)
    Battery Care Guide - Japanese(translated by a happy customer in Japan) (117.72 kB)
    Battery_Care_Guide (162.81 kB)
    Battery Care Guide - Japanese(translated by a happy customer in Japan) (117.72 kB)
    Battery_Care_Guide (162.81 kB)
    Battery Care Guide - Japanese(translated by a happy customer in Japan) (117.72 kB)
    eZee 48V 10Ah Lithium Battery with Sony Konion Cells Manual (400.56 kB)
    Battery Care Guide - Japanese(translated by a happy customer in Japan) (117.72 kB)
    Battery_Care_Guide (162.81 kB)
    Satiator User Manual for 1.0X Firmware (1.20 MB)
    Cycle Analyst Version 3.1 User Manual, Rev1.2 (2.46 MB)
    12 Pole PAS Specifications and Installation Guide (462.79 kB)
    12 Pole PAS Specifications and Installation Guide (462.79 kB)
    24 Pole PAS Specifications and Installation Guide (468.83 kB)
    24 Pole PAS Specifications and Installation Guide (468.83 kB)
    FAGTorqueSensingBBManual-Grin (281.79 kB)
    T17Manual (896.13 kB)
    T17Manual_1 (896.13 kB)
    T17Manual (896.13 kB)
    T17Manual (896.13 kB)
    TripWire Pull Specifications (426.56 kB)
    TripWire Push Short Specifications (425.65 kB)
    Statorade Specifications (44.44 kB)
    USB->TTL Programming Cable Manual (1.33 MB)
    Roxim Front Light Specifications (410.92 kB)
