Custom Motor Build

Have any of our unlaced hub motors built up into a rim size of your choosing.

From USD$140.00

To USD$777.00

In stock

SKU
BUNDLE-CustomBuild
Add to Wish List Add to Compare
Customize Custom Motor Build
Grin WheelBuild

* Required Fields

Your Customization
Custom Hub Motor Wheel Build
Custom Motor Build

In stock

USD$140.00

Summary

    Be aware that only the geared Bafang, eZee, GMAC, and SX motors can be laced into the 16" rim sizes. The direct drive motors are generally too large in diameter for this, with the exception of the Crystalyte SAW hub.

    Specifications
    MG310_Fst
    Actual Weight (kg)
    2.55
    Motor MFG
    Bafang
    Motor Power Range (Watts)
    250-500
    Motor KV (RPM / V)
    10.6
    Phase Resistance (Ohm)
    0.098
    Disk Brake Compatible
    Yes
    Connector(s)
    Z910
    Thermistor Style
    10K NTC, B ~3450 with 10K pullup (Bafang Style) Multiplexed with Speedo
    Axle Length (O.L.D.)
    138
    Axle Threads
    3/8" x 26 tpi
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    123
    Magnetic Pole Pairs (Phaserunner)
    88
    Hysteresis Losses (N-m)
    0.666
    Eddie Losses (N-m / rad/sec)
    0.015
    MG310_Std
    Actual Weight (kg)
    2.55
    Motor MFG
    Bafang
    Motor Power Range (Watts)
    250-500
    Motor KV (RPM / V)
    8.5
    Phase Resistance (Ohm)
    0.124
    Disk Brake Compatible
    Yes
    Connector(s)
    Z910
    Thermistor Style
    10K NTC, B ~3450 with 10K pullup (Bafang Style) Multiplexed with Speedo
    Axle Length (O.L.D.)
    138
    Axle Threads
    3/8" x 26 tpi
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    123
    Magnetic Pole Pairs (Phaserunner)
    88
    Hysteresis Losses (N-m)
    0.666
    Eddie Losses (N-m / rad/sec)
    0.015
    MG311 Fast Wind, Unlaced
    Actual Weight (kg)
    2.26
    Motor MFG
    Bafang
    Motor Power Range (Watts)
    250-500
    Motor KV (RPM / V)
    10.5
    Phase Resistance (Ohm)
    0.098
    Disk Brake Compatible
    Yes
    Connector(s)
    Z910
    Thermistor Style
    10K NTC, B ~3450 with 10K pullup (Bafang Style) Multiplexed with Speedo
    Axle Length (O.L.D.)
    100
    Axle Threads
    3/8" x 26 tpi
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    123
    Magnetic Pole Pairs (Phaserunner)
    88
    Hysteresis Losses (N-m)
    0.666
    Eddie Losses (N-m / rad/sec)
    0.015
    MG311 Standard Wind, Unlaced
    Actual Weight (kg)
    2.26
    Motor MFG
    Bafang
    Motor Power Range (Watts)
    250-500
    Motor KV (RPM / V)
    8.4
    Phase Resistance (Ohm)
    0.124
    Disk Brake Compatible
    Yes
    Connector(s)
    Z910
    Thermistor Style
    10K NTC, B ~3450 with 10K pullup (Bafang Style) Multiplexed with Speedo
    Axle Length (O.L.D.)
    100
    Axle Threads
    3/8" x 26 tpi
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    123
    Magnetic Pole Pairs (Phaserunner)
    88
    Hysteresis Losses (N-m)
    0.666
    Eddie Losses (N-m / rad/sec)
    0.015
    SX2 Fast Wind
    Actual Weight (kg)
    3.2
    Motor MFG
    Shengyi
    Motor Power Range (Watts)
    350-700
    Motor KV (RPM / V)
    9.8
    Phase Resistance (Ohm)
    0.072
    Disk Brake Compatible
    Yes
    Connector(s)
    Z910
    Thermistor Style
    10K NTC, Beta ~3450, Multiplexed with Speedo
    Axle Length (O.L.D.)
    135
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    141
    Magnetic Pole Pairs (Phaserunner)
    72
    Hysteresis Losses (N-m)
    0.43
    Eddie Losses (N-m / rad/sec)
    0.009
    SX2 Standard Wind
    Actual Weight (kg)
    3.2
    Motor MFG
    Shengyi
    Motor Power Range (Watts)
    350-700
    Motor KV (RPM / V)
    7.4
    Phase Resistance (Ohm)
    0.119
    Disk Brake Compatible
    Yes
    Connector(s)
    Z910
    Thermistor Style
    10K NTC, Beta ~3450, Multiplexed with Speedo
    Axle Length (O.L.D.)
    135
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    141
    Magnetic Pole Pairs (Phaserunner)
    72
    Hysteresis Losses (N-m)
    0.43
    Eddie Losses (N-m / rad/sec)
    0.009
    SX1 Fast Wind
    Actual Weight (kg)
    2.95
    Motor MFG
    Shengyi
    Motor Power Range (Watts)
    350-700
    Motor KV (RPM / V)
    9.8
    Phase Resistance (Ohm)
    0.072
    Disk Brake Compatible
    Yes
    Connector(s)
    Z910
    Thermistor Style
    10K NTC, Beta ~3450, Multiplexed with Speedo
    Axle Length (O.L.D.)
    100
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    141
    Magnetic Pole Pairs (Phaserunner)
    72
    Hysteresis Losses (N-m)
    0.43
    Eddie Losses (N-m / rad/sec)
    0.009
    SX1 Standard Wind
    Actual Weight (kg)
    2.95
    Motor MFG
    Shengyi
    Motor Power Range (Watts)
    350-700
    Motor KV (RPM / V)
    7.4
    Phase Resistance (Ohm)
    0.119
    Disk Brake Compatible
    Yes
    Connector(s)
    Z910
    Thermistor Style
    10K NTC, Beta ~3450, Multiplexed with Speedo
    Axle Length (O.L.D.)
    100
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    141
    Magnetic Pole Pairs (Phaserunner)
    72
    Hysteresis Losses (N-m)
    0.43
    Eddie Losses (N-m / rad/sec)
    0.009
    MSAW20F
    Actual Weight (kg)
    3.0
    Motor MFG
    Crystalyte
    Motor Power Range (Watts)
    250-500
    Motor KV (RPM / V)
    13.6
    Phase Resistance (Ohm)
    0.24
    Disk Brake Compatible
    No
    Connector(s)
    Z910
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    75
    Axle Threads
    M12 x 1.25mm
    Rim Brake Compatible
    Yes
    Rim Width (mm)
    24
    Spoke Holes
    36 Hole
    Motor Type
    Direct Drive
    Flange Spoke Diameter (mm)
    172
    Magnetic Pole Pairs (Phaserunner)
    20
    Hysteresis Losses (N-m)
    0.37
    Eddie Losses (N-m / rad/sec)
    0.006
    MG60 Fat_190
    Actual Weight (kg)
    4.2
    Motor MFG
    Bafang
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    8.2
    Phase Resistance (Ohm)
    0.080
    Disk Brake Compatible
    Yes
    Connector(s)
    Z910
    Axle Length (O.L.D.)
    190
    Axle Threads
    M12 x 1.25mm
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    145
    Magnetic Pole Pairs (Phaserunner)
    50
    Hysteresis Losses (N-m)
    0.58
    Eddie Losses (N-m / rad/sec)
    0.022
    Bafang MG62 Fatbike 170mm
    Manufacturer
    Bafang
    Actual Weight (kg)
    4.86
    Motor MFG
    Bafang
    Motor Power Range (Watts)
    600-1200
    Motor KV (RPM / V)
    8.0
    Phase Resistance (Ohm)
    0.055
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Axle Length (O.L.D.)
    170
    Axle Threads
    M12 x 1.25mm
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    143
    Magnetic Pole Pairs (Phaserunner)
    50
    Bafang MG62 Fatbike 190mm
    Manufacturer
    Bafang
    Actual Weight (kg)
    4.94
    Motor MFG
    Bafang
    Motor Power Range (Watts)
    600-1200
    Motor KV (RPM / V)
    8.0
    Phase Resistance (Ohm)
    0.055
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Axle Length (O.L.D.)
    190
    Axle Threads
    M12 x 1.25mm
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    143
    Magnetic Pole Pairs (Phaserunner)
    50
    GMAC8T
    Actual Weight (kg)
    3.82
    Motor MFG
    MAC Motor
    Motor Power Range (Watts)
    600-1200
    Motor KV (RPM / V)
    10.2
    Phase Resistance (Ohm)
    0.046
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    138
    Axle Threads
    M10 x 1.0mm
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    173
    Magnetic Pole Pairs (Phaserunner)
    80
    Hysteresis Losses (N-m)
    1.0
    Eddie Losses (N-m / rad/sec)
    0.013
    GMAC 10T
    Actual Weight (kg)
    3.82
    Motor MFG
    MAC Motor
    Motor Power Range (Watts)
    600-1200
    Motor KV (RPM / V)
    8.1
    Phase Resistance (Ohm)
    0.070
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    138
    Axle Threads
    M10 x 1.0mm
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    173
    Magnetic Pole Pairs (Phaserunner)
    80
    Hysteresis Losses (N-m)
    1.0
    Eddie Losses (N-m / rad/sec)
    0.013
    FH212_Fst
    Actual Weight (kg)
    6.16
    Motor MFG
    Nine Continent
    Motor Power Range (Watts)
    600-1200
    Motor KV (RPM / V)
    10.2
    Phase Resistance (Ohm)
    0.110
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Axle Threads
    M14 x 1.5mm
    Spoke Holes
    36 Hole
    Motor Type
    Direct Drive
    Flange Spoke Diameter (mm)
    238
    Magnetic Pole Pairs (Phaserunner)
    26
    Hysteresis Losses (N-m)
    0.715
    Eddie Losses (N-m / rad/sec)
    0.009
    FH212_Std
    Actual Weight (kg)
    6.16
    Motor MFG
    Nine Continent
    Motor Power Range (Watts)
    600-1200
    Motor KV (RPM / V)
    8.2
    Phase Resistance (Ohm)
    0.165
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Axle Threads
    M14 x 1.5mm
    Spoke Holes
    36 Hole
    Motor Type
    Direct Drive
    Flange Spoke Diameter (mm)
    238
    Magnetic Pole Pairs (Phaserunner)
    26
    Hysteresis Losses (N-m)
    0.715
    Eddie Losses (N-m / rad/sec)
    0.009
    RH212_Fst
    Actual Weight (kg)
    6.3
    Motor MFG
    Nine Continent
    Motor Power Range (Watts)
    600-1200
    Motor KV (RPM / V)
    10.2
    Phase Resistance (Ohm)
    0.110
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    136
    Axle Threads
    M14 x 1.5mm
    Spoke Holes
    36 Hole
    Motor Type
    Direct Drive
    Flange Spoke Diameter (mm)
    238
    Magnetic Pole Pairs (Phaserunner)
    26
    Hysteresis Losses (N-m)
    0.715
    Eddie Losses (N-m / rad/sec)
    0.009
    RH212_Std
    Actual Weight (kg)
    6.58
    Motor MFG
    Nine Continent
    Motor Power Range (Watts)
    600-1200
    Motor KV (RPM / V)
    8.2
    Phase Resistance (Ohm)
    0.165
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    136
    Axle Threads
    M14 x 1.5mm
    Spoke Holes
    36 Hole
    Motor Type
    Direct Drive
    Flange Spoke Diameter (mm)
    238
    Magnetic Pole Pairs (Phaserunner)
    26
    Hysteresis Losses (N-m)
    0.715
    Eddie Losses (N-m / rad/sec)
    0.009
    MeZee250F_L10
    Actual Weight (kg)
    3.78
    Motor MFG
    eZee
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    8.1
    Phase Resistance (Ohm)
    0.075
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Axle Threads
    M12 x 1.25mm
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    173
    Magnetic Pole Pairs (Phaserunner)
    80
    Hysteresis Losses (N-m)
    0.58
    Eddie Losses (N-m / rad/sec)
    0.039
    MeZee250R_L10
    Actual Weight (kg)
    3.82
    Motor MFG
    eZee
    Motor Nominal Wheel Size
    Unlaced
    Nominal Rim Size
    Unlaced
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    8.1
    Phase Resistance (Ohm)
    0.075
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    135
    Axle Threads
    M14 x 1.5mm
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    173
    Magnetic Pole Pairs (Phaserunner)
    80
    Hysteresis Losses (N-m)
    0.58
    Eddie Losses (N-m / rad/sec)
    0.039
    MeZee350F_L10
    Actual Weight (kg)
    3.66
    Motor MFG
    eZee
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    11.1
    Phase Resistance (Ohm)
    0.038
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Axle Threads
    M12 x 1.25mm
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    173
    Magnetic Pole Pairs (Phaserunner)
    80
    Hysteresis Losses (N-m)
    0.58
    Eddie Losses (N-m / rad/sec)
    0.039
    MeZee350R_L10
    Actual Weight (kg)
    3.86
    Motor MFG
    eZee
    Motor Nominal Wheel Size
    Unlaced
    Nominal Rim Size
    Unlaced
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    11.1
    Phase Resistance (Ohm)
    0.038
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    135
    Axle Threads
    M14 x 1.5mm
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    173
    Magnetic Pole Pairs (Phaserunner)
    80
    Hysteresis Losses (N-m)
    0.58
    Eddie Losses (N-m / rad/sec)
    0.039
    MeZee250F_RG
    Actual Weight (kg)
    3.78
    Motor MFG
    eZee
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    8.1
    Phase Resistance (Ohm)
    0.075
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Axle Threads
    M12 x 1.25mm
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    173
    Magnetic Pole Pairs (Phaserunner)
    80
    Hysteresis Losses (N-m)
    0.58
    Eddie Losses (N-m / rad/sec)
    0.039
    MeZee350F_RG
    Actual Weight (kg)
    3.78
    Motor MFG
    eZee
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    11.1
    Phase Resistance (Ohm)
    0.038
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Axle Threads
    M12 x 1.25mm
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    173
    Magnetic Pole Pairs (Phaserunner)
    80
    Hysteresis Losses (N-m)
    0.58
    Eddie Losses (N-m / rad/sec)
    0.039
    Torque Sensing Motor TSM-A5
    Motor MFG
    TDCM
    Motor Nominal Wheel Size
    Unlaced
    Nominal Rim Size
    Unlaced
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    9.3
    Phase Resistance (Ohm)
    0.185
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3450
    Axle Length (O.L.D.)
    135
    Spoke Holes
    36 Hole
    Motor Type
    Direct Drive
    Magnetic Pole Pairs (Phaserunner)
    16
    Hysteresis Losses (N-m)
    1.0
    Eddie Losses (N-m / rad/sec)
    0.00354
    Rim16Y303
    Actual Weight (kg)
    0.24
    Rim Width (mm)
    24
    Spoke Holes
    36 Hole
    Nominal Rim Size
    16" (ISO 305)
    Rim ERD
    292
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim16_ZAC19
    Actual Weight (kg)
    0.6
    Rim Width (mm)
    25
    Spoke Holes
    36 Hole
    Nominal Rim Size
    16" (ISO 349)
    Rim ERD
    332
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim20_ZAC19
    Actual Weight (kg)
    0.32
    Rim Width (mm)
    24
    Spoke Holes
    36 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim ERD
    389
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim20_DM30
    Actual Weight (kg)
    0.42
    Rim Width (mm)
    30
    Spoke Holes
    36 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim ERD
    394
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim20_Fat
    Actual Weight (kg)
    0.82
    Rim Width (mm)
    65
    Spoke Holes
    36 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim ERD
    384
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim24_DM30
    Actual Weight (kg)
    0.56
    Rim Width (mm)
    30
    Spoke Holes
    36 Hole
    Nominal Rim Size
    24" (ISO 507)
    Rim ERD
    494
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim24J31
    Actual Weight (kg)
    0.7000
    Rim Width (mm)
    31
    Spoke Holes
    36 Hole
    Nominal Rim Size
    24" (ISO 507)
    Rim ERD
    477
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim24_Fat
    Actual Weight (kg)
    1.02
    Rim Width (mm)
    65
    Spoke Holes
    36 Hole
    Nominal Rim Size
    24" (ISO 507)
    Rim ERD
    485
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim26_ZAC19
    Actual Weight (kg)
    0.46
    Rim Width (mm)
    23.6
    Spoke Holes
    36 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    540.33
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim26_DM30
    Actual Weight (kg)
    0.6
    Rim Width (mm)
    30
    Spoke Holes
    36 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    545
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim26J31
    Actual Weight (kg)
    0.7800
    Rim Width (mm)
    31
    Spoke Holes
    36 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    527
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim26_Fat
    Actual Weight (kg)
    1.06
    Rim Width (mm)
    65
    Spoke Holes
    36 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    537
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim26_Fat80
    Actual Weight (kg)
    .830
    Rim Width (mm)
    80
    Spoke Holes
    36 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    542
    Rim Brake Compatible
    No
    Rim275_DM30
    Actual Weight (kg)
    0.76
    Rim Width (mm)
    30
    Spoke Holes
    36 Hole
    Nominal Rim Size
    650B (ISO 584)
    Rim ERD
    565
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim700_ZAC19
    Actual Weight (kg)
    0.5
    Rim Width (mm)
    23.6
    Spoke Holes
    36 Hole
    Nominal Rim Size
    700C (ISO 622)
    Rim ERD
    603.86
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim700_DM30
    Actual Weight (kg)
    0.65
    Rim Width (mm)
    30
    Spoke Holes
    36 Hole
    Nominal Rim Size
    700C (ISO 622)
    Rim ERD
    609
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    More Information
    Product Attachments
    MG310 Installation Manual (300.68 kB)
    G310 Motor Dimensional Diagram (87.29 kB)
    MG310 Installation Manual (300.68 kB)
    G310 Motor Dimensional Diagram (87.29 kB)
    G311 Motor Dimensional Diagram (65.46 kB)
    G311 Motor Dimensional Diagram (65.46 kB)
    SX2 Motor Dimensional Diagram (98.75 kB)
    SX2 Motor Dimensional Diagram (98.75 kB)
    SX1 Motor Dimensional Diagram (104.13 kB)
    SX1 Motor Dimensional Diagram (104.13 kB)
    Shengyi Motor 3D IGS file (1.32 MB)
    Crystalyte SAW Motor Dimensional Diagram (77.82 kB)
    G60 Motor (190mm O.L.D.) Dimensional Diagram (89.93 kB)
    MG62_170 Dimensional Drawing (101.74 kB)
    MG62_170 3D Part File (8.34 MB)
    MG62_190 Dimensional Diagram (100.61 kB)
    MG62_190 3D Part File (8.26 MB)
    GMAC Installation Guide (1.81 MB)
    GMAC Motor Dimensional Diagram (73.18 kB)
    GMAC Installation Guide (1.81 MB)
    GMAC Motor Dimensional Diagram (73.18 kB)
    FH212 Motor Dimensional Diagram (74.86 kB)
    FH212 3D CAD Model (7.33 MB)
    FH212 Motor Dimensional Diagram (74.86 kB)
    RH212 Motor Dimensional Diagram (73.65 kB)
    RH212 Motor Dimensional Diagram (73.65 kB)
    eZee Front Motor Dimensional Diagram (87.28 kB)
    eZee Gen2 Motor Dimensional Diagram (55.85 kB)
    eZee_17Years_Story (16.55 MB)
    eZee Front Motor Dimensional Diagram (87.28 kB)
    eZee Gen2 Motor Dimensional Diagram (55.85 kB)
    eZee_17Years_Story (16.55 MB)
    TSM-A5 Installation Guide (2.64 MB)
    TDCM HCA5 Motor Dimensional Drawing (70.99 kB)
    Torque Arm G311 Installation and Specifications (479.27 kB)
    Torque Arm V2 Installation and Specifications (65.42 kB)
    Torque Arm V3 Installation and Specifications (74.75 kB)
    Torque Arm V4 Installation and Specifications (473.60 kB)
    TA_V5_Manual_rev0 (894.44 kB)
    TA_V6_Manual_rev0 (905.60 kB)
    TA_V7_Manual_Rev1 (1.12 MB)
    GMAC Installation Guide (1.81 MB)
