NCTE Square Taper Torque Sensor (Similar to THUN), Extra Long 136mm Spindle.
SKU
BB-NCTE_136
NCTE square taper torque sensing bottom bracket, extra long 136mm spindle can be useful on mid-drive or tandem setups. Terminated with male JST pins to plug directly to the V3 CA with no extra cable harness.
This torque sensing bottom bracket has the same specifications as the THUN sensors, with an 8-pole cadence sensor and measures the actual torque across the spindle. It gives the most accurate human power statistics but it only senses the left pedal force, so there can be some delay in pedalec assistance if you start from a standstill pushing on the right crank.
For more information on torque sensors, see our Advanced PAS Kit Info Page
| Country of Manufacture | Germany |
|---|---|
| Actual Weight (kg) | 0.3300 |
| Connector(s) | JST-SM |
| PAS Poles | 16 |
| PAS Encoder Type | 2 Wire (Quadrature) |
| Sensor Supply Voltage | 10-16V |
| Torque Scale | -200 Nm/V |
| Torque Sensor Offset Voltage | 2.5V |
