Front Folding Bike Ready-to-Roll Kit

Front 250-500W Ready to Roll Kit with 250-300 Watt Direct Drive Hub Motor, Downtube Battery, Baserunner, V3 Cycle Analyst and PAS/Torque Sensor Options.

From USD$615.00

To USD$2,091.00

In stock

SKU
KIT-MFSAW20F_RTR
Add to Wish List Add to Compare
Customize Front Folding Bike Ready-to-Roll Kit

* Required Fields

Your Customization
Ready to Roll Kit with G311 Front Motor, Downtube Battery, Baserunner Controller, PAS/Torque sensors etc.
Front Folding Bike Ready-to-Roll Kit

In stock

USD$615.00

Actual cruising speed/perfomance under any loading conditions is well modeled in our simulator. NEW! Launch Motor Simulator with Front Folding Bike Ready-to-Roll Kit

Summary

    Front wheel conversion kit for folding bicycles based around a 250-500 Watt Direct-Drive motor with the standard M12 Axle with 10mm flats. For Dahon, Bike Friday, and similar folding bikes with narrow 75mm forks but standard dropout width. Including the Baserunner motor controller tucked neatly in a downtube battery, the CA3 with accessories, and pedal assist systems. This setup includes everything configured out of the box for the ideal for a minimal, lightweight commuter ebike with pedalec control.

    For details on the PAS/Torque sensor selection, see the Advanced PAS Kit Info Page

    Specifications
    MSAW20F
    Actual Weight (kg)
    3.0
    Motor MFG
    Crystalyte
    Motor Power Range (Watts)
    250-500
    Motor KV (RPM / V)
    13.6
    Phase Resistance (Ohm)
    0.24
    Disk Brake Compatible
    No
    Connector(s)
    Z910
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    75
    Axle Threads
    M12 x 1.25mm
    Rim Brake Compatible
    Yes
    Rim Width (mm)
    24
    Spoke Holes
    36 Hole
    Flange Spoke Diameter (mm)
    172
    Magnetic Pole Pairs (Phaserunner)
    20
    Hysteresis Losses (N-m)
    0.37
    Eddie Losses (N-m / rad/sec)
    0.006
    Rim16_ZAC19
    Actual Weight (kg)
    0.6
    Rim Width (mm)
    25
    Spoke Holes
    36 Hole
    Nominal Rim Size
    16" (ISO 349)
    Rim ERD
    332
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim16Frct
    Actual Weight (kg)
    0.2100
    Rim Width (mm)
    20
    Spoke Holes
    36 Hole
    Nominal Rim Size
    16" (ISO 349)
    Rim ERD
    328
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim16Y303
    Actual Weight (kg)
    0.24
    Rim Width (mm)
    24
    Spoke Holes
    36 Hole
    Nominal Rim Size
    16" (ISO 305)
    Rim ERD
    292
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim20_ZAC19
    Actual Weight (kg)
    0.32
    Rim Width (mm)
    24
    Spoke Holes
    36 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim ERD
    389
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim20_DM30
    Actual Weight (kg)
    0.42
    Rim Width (mm)
    30
    Spoke Holes
    36 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim ERD
    394
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim24J31
    Actual Weight (kg)
    0.7000
    Rim Width (mm)
    31
    Spoke Holes
    36 Hole
    Nominal Rim Size
    24" (ISO 507)
    Rim ERD
    477
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    B3615Li-DT
    Actual Weight (kg)
    3.15
    Dimensions (L x W x H, mm)
    365x95x100
    Mounting Type
    Frame Mount
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    14.5
    Cell Type
    Panasonic NCR21700A 10S x 3P
    Connector(s)
    Anderson, DT_4pinSpade, ST3
    B3617LiM-DT
    Actual Weight (kg)
    3.54
    Dimensions (L x W x H, mm)
    370x89x90
    Mounting Type
    Frame Mount
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    16.8
    Watt-hours at 1C Discharge
    600
    Cell Type
    Samsung INR 1865035E 10S x 5P
    Internal Resistance (Ohms)
    0.1
    Connector(s)
    Anderson, ST3
    B3620Li-DT
    Actual Weight (kg)
    4.02
    Dimensions (L x W x H, mm)
    365x95x100
    Mounting Type
    Frame Mount
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    19.25
    Cell Type
    Panasonic NCR21700A 10S x 4P
    Connector(s)
    Anderson, DT_4pinSpade, ST3
    B3624LiM-DT
    Actual Weight (kg)
    4.8
    Dimensions (L x W x H, mm)
    365x95x124
    Mounting Type
    Frame Mount, Rear Rack
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42
    Capacity (Amp-Hours)
    24
    Cell Type
    Panasonic 21700A 10S x 5P
    Internal Resistance (Ohms)
    0.80
    Connector(s)
    Anderson, ST3
    B3626LiM-DT
    Actual Weight (kg)
    5.18
    Dimensions (L x W x H, mm)
    370x89x137
    Mounting Type
    Frame Mount
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    26.5
    Cell Type
    Panasonic NCR18650GA 10S x 8P
    Internal Resistance (Ohms)
    0.06
    Connector(s)
    Anderson, ST3
    36V 2A ST3 Charger
    Actual Weight (kg)
    0.36
    Connector(s)
    ST3
    36V 4A ST3 Charger 220VAC
    Actual Weight (kg)
    0.58
    Connector(s)
    ST3
    Satiator Upgrade with ST3 Adapter
    Actual Weight (kg)
    1.06
    Baserunner_Z9
    Manufacturer
    Grin
    Dimensions (L x W x H, mm)
    90 x 55 x 15
    Actual Weight (kg)
    0.18
    Max Regen Voltage (V)
    60
    Max Battery Amps (A)
    30
    Max Phase Amps (A)
    55
    Battery Range (V)
    20-60
    Connector(s)
    HiGo 0812(WP8), JST-SM, TRRS, Z910
    CA3-WPx
    Actual Weight (kg)
    0.3
    12 Pole PAS with Spindle Mounted Magdisc
    Manufacturer
    King Meter
    Actual Weight (kg)
    0.12
    PAS Poles
    12
    PAS Encoder Type
    2 Wire (Quadrature)
    12 Pole PAS with Chainring Mounted Magdisc
    PAS Poles
    12
    PAS Encoder Type
    2 Wire (Quadrature)
    24 Pole PAS (Short 90cm Cable)
    Actual Weight (kg)
    .06
    Connector(s)
    JST-SM
    PAS Poles
    24
    PAS Encoder Type
    2 Wire (Quadrature)
    24 Pole PAS (Long 120cm Cable)
    Actual Weight (kg)
    .06
    Connector(s)
    JST-SM
    PAS Poles
    24
    PAS Encoder Type
    2 Wire (Quadrature)
    Fischer AG Torque Sensing BB, 127mm
    Actual Weight (kg)
    0.3300
    Connector(s)
    JST-SM, HiGo MiniB
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    0.6
    ERider68-T17 BB with 4 Arm Spider
    Actual Weight (kg)
    1.06
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    ERider68-T17 BB with 5 Arm Spider
    Actual Weight (kg)
    1.06
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    ERider73-T17 BB with 4 Arm Spider
    Actual Weight (kg)
    1.06
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    ERider73-T17 BB with 5 Arm Spider
    Actual Weight (kg)
    1.06
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    NCTE_120
    Actual Weight (kg)
    0.3300
    Connector(s)
    JST-SM
    PAS Poles
    16
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    2.5V
    NCTE_128
    Actual Weight (kg)
    0.3300
    Connector(s)
    JST-SM
    PAS Poles
    16
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    2.5V
    More Information
    Product Attachments
    Crystalyte SAW Motor Dimensional Diagram (77.82 kB)
    Torque Arm V2 Installation and Specifications (65.42 kB)
    Torque Arm V3 Installation and Specifications (74.75 kB)
    Satiator User Manual for 1.0X Firmware (1.20 MB)
    V4 Baserunner_Z9 3D IGS File (482.55 kB)
    12 Pole PAS Specifications and Installation Guide (462.79 kB)
    12 Pole PAS Specifications and Installation Guide (462.79 kB)
    24 Pole PAS Specifications and Installation Guide (468.83 kB)
    24 Pole PAS Specifications and Installation Guide (468.83 kB)
    FAGTorqueSensingBBManual-Grin (281.79 kB)
    T17Manual (896.13 kB)
    T17Manual_1 (896.13 kB)
    T17Manual (896.13 kB)
    T17Manual (896.13 kB)
    NCTE Bottom Bracket Specifications (532.39 kB)
    NCTE Bottom Bracket Specifications (532.39 kB)
    TripWire Pull Specifications (426.56 kB)
    TripWire Push Short Specifications (425.65 kB)
    USB->TTL Programming Cable Manual (1.33 MB)
