GMAC Minimal Kit

Rear Geared GMAC Motor Kit. Minimal Parts for Basic Throttle Control.

Full Product Information Page

From USD$765.00

To USD$2,380.00

In stock

SKU
KIT-GMAC_Min
Add to Wish List Add to Compare
Customize GMAC Minimal Kit

* Required Fields

Your Customization
9C RH212 Minimal Motor Kit, Basic Throttle Control
GMAC Minimal Kit

In stock

USD$765.00

Actual cruising speed/perfomance under any loading conditions is well modeled in our simulator. NEW! Launch Motor Simulator with GMAC Minimal Kit

Summary
    GMAC8T
    ETA
    Jun. 19, 2022
    Actual Weight (kg)
    3.82
    Motor MFG
    MAC Motor
    Motor Power Range (Watts)
    600-1200
    Motor KV (RPM / V)
    10.2
    Phase Resistance (Ohm)
    0.046
    Disk Brake Compatible
    Yes
    Spoke Holes
    36 Hole
    Flange Spoke Diameter (mm)
    173
    Magnetic Pole Pairs (Phaserunner)
    80
    Hysteresis Losses (N-m)
    1.0
    Eddie Losses (N-m / rad/sec)
    0.013
    GMAC10T
    ETA
    Jun. 13, 2021
    Actual Weight (kg)
    3.82
    Motor MFG
    MAC Motor
    Motor Power Range (Watts)
    600-1200
    Motor KV (RPM / V)
    8.1
    Phase Resistance (Ohm)
    0.070
    Disk Brake Compatible
    Yes
    Spoke Holes
    36 Hole
    Flange Spoke Diameter (mm)
    173
    Magnetic Pole Pairs (Phaserunner)
    80
    Hysteresis Losses (N-m)
    1.0
    Eddie Losses (N-m / rad/sec)
    0.013
    CS7Spd1134_SR
    Actual Weight (kg)
    0.226
    CS7Spd1132
    Actual Weight (kg)
    0.226
    CS8Spd1132
    Actual Weight (kg)
    0.286
    CS8Spd1132_SR
    Actual Weight (kg)
    0.286
    CS9Spd1132
    Actual Weight (kg)
    0.364
    CS9Spd1132_SR
    Actual Weight (kg)
    0.364
    CS10Spd1132
    Actual Weight (kg)
    0.364
    CS10Spd1134_SR
    Actual Weight (kg)
    0.364
    Rim16_ZAC19
    Actual Weight (kg)
    0.6
    Rim Width (mm)
    25
    Spoke Holes
    36 Hole
    Nominal Rim Size
    16" (ISO 349)
    Rim ERD
    332
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim16Y303
    Actual Weight (kg)
    0.24
    Rim Width (mm)
    24
    Spoke Holes
    36 Hole
    Nominal Rim Size
    16" (ISO 305)
    Rim ERD
    292
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim16Frct
    Actual Weight (kg)
    0.2100
    Rim Width (mm)
    20
    Spoke Holes
    36 Hole
    Nominal Rim Size
    16" (ISO 349)
    Rim ERD
    328
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim20_ZAC19
    Actual Weight (kg)
    0.32
    Rim Width (mm)
    24
    Spoke Holes
    36 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim ERD
    389
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim20_Weinmann
    Actual Weight (kg)
    0.42
    Rim Width (mm)
    30
    Spoke Holes
    36 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim ERD
    394
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim20_Fat
    Actual Weight (kg)
    0.82
    Rim Width (mm)
    65
    Spoke Holes
    36 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim ERD
    384
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim24J31
    Actual Weight (kg)
    0.7000
    Rim Width (mm)
    31
    Spoke Holes
    36 Hole
    Nominal Rim Size
    24" (ISO 507)
    Rim ERD
    477
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim24_Ryde
    Actual Weight (kg)
    0.72
    Rim Width (mm)
    31
    Spoke Holes
    36 Hole
    Nominal Rim Size
    24" (ISO 507)
    Rim ERD
    483
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim26_ZAC19
    Actual Weight (kg)
    0.46
    Rim Width (mm)
    23.6
    Spoke Holes
    36 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    540.33
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim26_Alex
    Actual Weight (kg)
    0.76
    Rim Width (mm)
    32
    Spoke Holes
    36 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    544
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim26_Weinmann
    Actual Weight (kg)
    0.6
    Rim Width (mm)
    30
    Spoke Holes
    36 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    545
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim26_Fat
    Actual Weight (kg)
    1.06
    Rim Width (mm)
    65
    Spoke Holes
    36 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    537
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim26_Fat80
    Actual Weight (kg)
    .830
    Rim Width (mm)
    80
    Spoke Holes
    36 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    542
    Rim Brake Compatible
    No
    Rim275_Alex
    Actual Weight (kg)
    0.76
    Rim Width (mm)
    32
    Spoke Holes
    36 Hole
    Nominal Rim Size
    650B (ISO 584)
    Rim ERD
    565
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim275_J36U
    Actual Weight (kg)
    .6
    Rim Width (mm)
    41MM
    Spoke Holes
    36 Hole
    Nominal Rim Size
    650B (ISO 584)
    Rim ERD
    566
    Rim Brake Compatible
    No
    Valve Type
    Presta, Schrader
    Rim275_XM280
    Actual Weight (kg)
    .55
    Rim Width (mm)
    21
    Spoke Holes
    36 Hole
    Nominal Rim Size
    650B (ISO 584)
    Rim ERD
    560
    Rim Brake Compatible
    No
    Valve Type
    Presta, Schrader
    Rim700_ZAC19
    Actual Weight (kg)
    0.5
    Rim Width (mm)
    23.6
    Spoke Holes
    36 Hole
    Nominal Rim Size
    700C (ISO 622)
    Rim ERD
    603.86
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim700_Weinmann
    Actual Weight (kg)
    0.65
    Rim Width (mm)
    30
    Spoke Holes
    36 Hole
    Nominal Rim Size
    700C (ISO 622)
    Rim ERD
    609
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Baserunner_L10
    Dimensions (L x W x H, mm)
    90 x 55 x 15
    Actual Weight (kg)
    0.18
    Max Battery Amps (A)
    35
    Max Phase Amps (A)
    70
    Battery Range (V)
    20-60
    Phaserunner_L10
    ETA
    Nov. 14, 2022
    Dimensions (L x W x H, mm)
    99 x 40 x 34
    Actual Weight (kg)
    0.26
    Max Battery Amps (A)
    40
    Max Phase Amps (A)
    80
    Battery Range (V)
    30-90
    Phaserunner_L10_Bk
    ETA
    Jun. 9, 2021
    Dimensions (L x W x H, mm)
    99 x 40 x 34
    Actual Weight (kg)
    0.26
    Max Battery Amps (A)
    40
    Max Phase Amps (A)
    96
    Battery Range (V)
    30-90
    B3615Li-DT
    Actual Weight (kg)
    3.15
    Dimensions (L x W x H, mm)
    365x95x100
    Mounting Type
    Frame Mount
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    14.5
    Cell Type
    Panasonic NCR21700A 10S x 3P
    B3620Li-DT
    Actual Weight (kg)
    4.02
    Dimensions (L x W x H, mm)
    365x95x100
    Mounting Type
    Frame Mount
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    19.25
    Cell Type
    Panasonic NCR21700A 10S x 4P
    B3626LiM-DT
    Actual Weight (kg)
    5.18
    Dimensions (L x W x H, mm)
    370x89x137
    Mounting Type
    Frame Mount
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    26.5
    Cell Type
    Panasonic NCR18650GA 10S x 8P
    Internal Resistance (Ohms)
    0.06
    B4819LiM-DT
    Actual Weight (kg)
    4.9
    Dimensions (L x W x H, mm)
    365x100x124
    Mounting Type
    Frame Mount, Rear Rack
    Nominal Voltage
    48 Volt (13s)
    Full Charge Voltage
    54.6
    Capacity (Amp-Hours)
    19
    Cell Type
    Panasonic 27100 A 13S x 4P
    Internal Resistance (Ohms)
    0.10
    B5215Li-DT
    Actual Weight (kg)
    4.28
    Dimensions (L x W x H, mm)
    380x95x100
    Mounting Type
    Frame Mount
    Nominal Voltage
    52 Volt (14s)
    Full Charge Voltage
    58.8
    Capacity (Amp-Hours)
    14.5
    Cell Type
    Panasonic NCR21700A 14S x 3P
    B5216LiM-DT
    Actual Weight (kg)
    4.35
    Dimensions (L x W x H, mm)
    370x89x110
    Mounting Type
    Frame Mount
    Nominal Voltage
    52 Volt (14s)
    Full Charge Voltage
    58.8
    Capacity (Amp-Hours)
    16.5
    Cell Type
    Panasonic NCR18650GA 14S x 5P
    Internal Resistance (Ohms)
    0.14
    52V 20Ah (14S) DT Battery,Reention
    Actual Weight (kg)
    5.38
    Dimensions (L x W x H, mm)
    370x89x137
    Mounting Type
    Frame Mount
    Nominal Voltage
    52 Volt (14s)
    Full Charge Voltage
    58.8
    Capacity (Amp-Hours)
    19.8
    Cell Type
    Samsung 18650 35E 14S x 6P
    Internal Resistance (Ohms)
    0.12
    36V 2A ST3 Charger
    Actual Weight (kg)
    0.36
    36V 4A ST3 Charger 100-240VAC
    Actual Weight (kg)
    0.58
    48V 2A ST3 Charger 100 - 240VAC
    Actual Weight (kg)
    0.48
    52V 4A ST-3 Charger 100-240VAC
    Actual Weight (kg)
    0.84
    Satiator Upgrade with ST3 Adapter
    Actual Weight (kg)
    1.06
    More Information
    GMAC Installation Guide (1.81 MB)
    GMAC Motor Dimensional Diagram (73.18 kB)
    GMAC Installation Guide (1.81 MB)
    GMAC Motor Dimensional Diagram (73.18 kB)
    GMAC Installation Guide (1.81 MB)
    Phaserunner Dimensional Diagram (111.82 kB)
    Satiator User Manual for 1.0X Firmware (1.20 MB)

    Conversion kit based around the GMAC geared hub motor for basic throttle control without PAS. Includes high torque motor with locked clutch for regen, downtube battery pack with integrated Baserunner_L10 motor controller, wheelbuild options.

    For a full explanation of the various drop-down choices and a comparison of this package versus other motor options, see our Grin Kits Info Page
