SX2 Rear Ready-to-Roll Kit

Rear 250-500W Ready-to-Roll SX2 Kit, V3 Cycle Analyst, Downtube battery, PAS/Torque sensor options.

Full Product Information Page

From USD$575.00

To USD$3,092.00

In stock

SKU
KIT-SX2_RTR
Add to Wish List Add to Compare
Customize SX2 Rear Ready-to-Roll Kit
V5 Baserunner_Z9
CA3-WPx
CA3_MFSwitch for CA3-WPx

* Required Fields

Your Customization
Ready to Roll Kit based on Rear G310 Motor, Downtube Battery with Baserunner Controller, CA3 with PAS Options etc.
SX2 Rear Ready-to-Roll Kit

In stock

USD$575.00

Actual cruising speed/perfomance under any loading conditions is well modeled in our simulator.
Launch Motor Simulator with SX2 Rear Ready-to-Roll Kit

Summary
    Complete conversion kit based around the Shengyi SX2 mid-sized silent geared hub motors, including the baserunner motor controller tucked neatly in a downtube battery, the CA3 with accessories and pedal assist systems. The motor has built in speed and temperature sensing for automatic thermal rollback with the CA3 so that there is no risk of burning up the motor on long climbs.

    This setup includes everything configured out of the box for a lightweight commuter ebike with pedalec control.

    For a full explanation of the various drop-down choices and a comparison of this package versus other motor options, see our Grin Kits Info Page

    For details on this hub in particular, see the Shengyi X1 / X2 Geared Motor Info Page

    For details on the PAS/Torque sensor selection, see the PAS Info Page

    Specifications
    SX2 Standard Wind
    Actual Weight (kg)
    3.2
    Motor MFG
    Shengyi
    Motor Power Range (Watts)
    350-700
    Motor KV (RPM / V)
    7.4
    Phase Resistance (Ohm)
    0.119
    Disk Brake Compatible
    Yes
    Connector(s)
    Z910
    Thermistor Style
    10K NTC, Beta ~3450, Multiplexed with Speedo
    Axle Length (O.L.D.)
    135
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    141
    Magnetic Pole Pairs (Phaserunner)
    72
    Hysteresis Losses (N-m)
    0.43
    Eddie Losses (N-m / rad/sec)
    0.009
    SX2 Fast Wind
    Actual Weight (kg)
    3.2
    Motor MFG
    Shengyi
    Motor Power Range (Watts)
    350-700
    Motor KV (RPM / V)
    9.8
    Phase Resistance (Ohm)
    0.072
    Disk Brake Compatible
    Yes
    Connector(s)
    Z910
    Thermistor Style
    10K NTC, Beta ~3450, Multiplexed with Speedo
    Axle Length (O.L.D.)
    135
    Spoke Holes
    36 Hole
    Motor Type
    Geared
    Flange Spoke Diameter (mm)
    141
    Magnetic Pole Pairs (Phaserunner)
    72
    Hysteresis Losses (N-m)
    0.43
    Eddie Losses (N-m / rad/sec)
    0.009
    7 Speed Cassette, 11-32 Tooth
    Actual Weight (kg)
    0.226
    Cluster Type
    Freehub Cluster
    8 Speed Cassette, 11-32 Tooth
    Actual Weight (kg)
    0.286
    Cluster Type
    Freehub Cluster
    9 Speed Cassette, 11-32 Tooth
    Actual Weight (kg)
    0.364
    Cluster Type
    Freehub Cluster
    10 Speed Cassette, 11-32 Tooth
    Actual Weight (kg)
    0.364
    Cluster Type
    Freehub Cluster
    Rim16Y303
    Actual Weight (kg)
    0.24
    Rim Width (mm)
    24
    Spoke Holes
    36 Hole
    Nominal Rim Size
    16" (ISO 305)
    Rim ERD
    292
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim16_ZAC19
    Actual Weight (kg)
    0.6
    Rim Width (mm)
    25
    Spoke Holes
    36 Hole
    Nominal Rim Size
    16" (ISO 349)
    Rim ERD
    332
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim20_ZAC19
    Actual Weight (kg)
    0.32
    Rim Width (mm)
    24
    Spoke Holes
    36 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim ERD
    389
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim20_DM30
    Actual Weight (kg)
    0.42
    Rim Width (mm)
    30
    Spoke Holes
    36 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim ERD
    394
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim20_Fat
    Actual Weight (kg)
    0.82
    Rim Width (mm)
    65
    Spoke Holes
    36 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim ERD
    384
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim24_DM30
    Actual Weight (kg)
    0.56
    Rim Width (mm)
    30
    Spoke Holes
    36 Hole
    Nominal Rim Size
    24" (ISO 507)
    Rim ERD
    494
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim24J31
    Actual Weight (kg)
    0.7000
    Rim Width (mm)
    31
    Spoke Holes
    36 Hole
    Nominal Rim Size
    24" (ISO 507)
    Rim ERD
    477
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim24_Fat
    Actual Weight (kg)
    1.02
    Rim Width (mm)
    65
    Spoke Holes
    36 Hole
    Nominal Rim Size
    24" (ISO 507)
    Rim ERD
    485
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim26_ZAC19
    Actual Weight (kg)
    0.46
    Rim Width (mm)
    23.6
    Spoke Holes
    36 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    540.33
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim26_DM30
    Actual Weight (kg)
    0.6
    Rim Width (mm)
    30
    Spoke Holes
    36 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    545
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim26J31
    Actual Weight (kg)
    0.7800
    Rim Width (mm)
    31
    Spoke Holes
    36 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    527
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim26_Fat
    Actual Weight (kg)
    1.06
    Rim Width (mm)
    65
    Spoke Holes
    36 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    537
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim26_Fat80
    Actual Weight (kg)
    .830
    Rim Width (mm)
    80
    Spoke Holes
    36 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    542
    Rim Brake Compatible
    No
    Rim275_DM30
    Actual Weight (kg)
    0.76
    Rim Width (mm)
    30
    Spoke Holes
    36 Hole
    Nominal Rim Size
    650B (ISO 584)
    Rim ERD
    565
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim700_ZAC19
    Actual Weight (kg)
    0.5
    Rim Width (mm)
    23.6
    Spoke Holes
    36 Hole
    Nominal Rim Size
    700C (ISO 622)
    Rim ERD
    603.86
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim700_DM30
    Actual Weight (kg)
    0.65
    Rim Width (mm)
    30
    Spoke Holes
    36 Hole
    Nominal Rim Size
    700C (ISO 622)
    Rim ERD
    609
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    36V 10Ah Bottle Battery
    Actual Weight (kg)
    2.2
    Dimensions (L x W x H, mm)
    295x78x78
    Mounting Type
    Frame Mount
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    9.8
    Watt-hours at 1C Discharge
    345
    Cell Type
    Panasonic GA 10S x 4P
    Internal Resistance (Ohms)
    0.19
    Connector(s)
    Anderson, ST3
    36V 14Ah Bottle Battery
    Actual Weight (kg)
    2.7
    Dimensions (L x W x H, mm)
    363x78x78
    Mounting Type
    Frame Mount
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    13.3
    Watt-hours at 1C Discharge
    460
    Cell Type
    Panasonic GA 10S x 4P
    Internal Resistance (Ohms)
    0.160
    Connector(s)
    Anderson, ST3
    36V 14.5Ah Downtube Battery
    Actual Weight (kg)
    3.15
    Dimensions (L x W x H, mm)
    365x100x105
    Mounting Type
    Frame Mount
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    14.5
    Cell Type
    NCR21700A 10S x 3P
    Connector(s)
    Anderson, DT_4pinSpade, ST3
    36V 15.5Ah eZee Flat Pack
    Manufacturer
    eZee
    Actual Weight (kg)
    3.5
    Dimensions (L x W x H, mm)
    348x141x59
    Mounting Type
    Rear Rack
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42
    Capacity (Amp-Hours)
    15.5
    Cell Type
    LG 18650 MH1, 10S x 5P
    Internal Resistance (Ohms)
    0
    Connector(s)
    Anderson, XLR
    36V 20Ah Downtube Battery
    Actual Weight (kg)
    4.02
    Dimensions (L x W x H, mm)
    365x95x100
    Mounting Type
    Frame Mount
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    19.25
    Cell Type
    Panasonic NCR21700A 10S x 4P
    Connector(s)
    Anderson, DT_4pinSpade, ST3
    36V 22Ah eZee Flat Pack
    Manufacturer
    eZee
    Actual Weight (kg)
    4.4
    Dimensions (L x W x H, mm)
    348x141x59
    Mounting Type
    Rear Rack
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42
    Capacity (Amp-Hours)
    21.5
    Cell Type
    LG 18650 MH1, 10S x 7P
    Internal Resistance (Ohms)
    0
    Connector(s)
    Anderson, XLR
    36V 24Ah Downtube Battery
    Actual Weight (kg)
    4.8
    Dimensions (L x W x H, mm)
    365x95x124
    Mounting Type
    Frame Mount, Rear Rack
    Nominal Voltage
    36 Volt (10s)
    Full Charge Voltage
    42
    Capacity (Amp-Hours)
    24
    Cell Type
    Panasonic 21700A 10S x 5P
    Internal Resistance (Ohms)
    0.80
    Connector(s)
    Anderson, ST3
    48V 10Ah Bottle Battery
    Actual Weight (kg)
    2.7
    Dimensions (L x W x H, mm)
    363x78x78
    Mounting Type
    Frame Mount
    Nominal Voltage
    48 Volt (13s)
    Full Charge Voltage
    42.0
    Capacity (Amp-Hours)
    9.9
    Watt-hours at 1C Discharge
    450
    Cell Type
    Panasonic GA 13S x 3P
    Internal Resistance (Ohms)
    0.170
    Connector(s)
    Anderson, ST3
    48V 14.5Ah Downtube Battery
    Actual Weight (kg)
    4.0
    Dimensions (L x W x H, mm)
    365x100x105
    Mounting Type
    Frame Mount
    Nominal Voltage
    48 Volt (13s)
    Full Charge Voltage
    54.5
    Cell Type
    NCR 21700 A 13S x 3P
    Connector(s)
    Anderson, DT_4pinSpade
    48V 15.5Ah eZee Flat Pack
    Manufacturer
    eZee
    Actual Weight (kg)
    7.8
    Dimensions (L x W x H, mm)
    348x141x59
    Mounting Type
    Rear Rack
    Nominal Voltage
    48 Volt (13s)
    Full Charge Voltage
    54.5
    Capacity (Amp-Hours)
    15.5
    Cell Type
    LG 18650 MH1, 13S x 5P
    Internal Resistance (Ohms)
    0.156
    Connector(s)
    Anderson, XLR
    48V 17Ah eZee Flat Pack
    Manufacturer
    eZee
    Actual Weight (kg)
    4.3
    Dimensions (L x W x H, mm)
    348x141x59
    Mounting Type
    Rear Rack
    Nominal Voltage
    48 Volt (13s)
    Full Charge Voltage
    54.5
    Capacity (Amp-Hours)
    16.5
    Cell Type
    Samsung 35E 13S x 5P
    Internal Resistance (Ohms)
    0.120
    Connector(s)
    Anderson, XLR
    48V 19Ah Downtube Battery
    Actual Weight (kg)
    4.9
    Dimensions (L x W x H, mm)
    365x100x124
    Mounting Type
    Frame Mount
    Nominal Voltage
    48 Volt (13s)
    Full Charge Voltage
    54.6
    Capacity (Amp-Hours)
    19
    Cell Type
    Panasonic 27100 A 13S x 4P
    Internal Resistance (Ohms)
    0.12
    Connector(s)
    Anderson, ST3
    52V 15Ah Downtube Battery
    Actual Weight (kg)
    4.3
    Dimensions (L x W x H, mm)
    380x95x100
    Mounting Type
    Frame Mount
    Nominal Voltage
    52 Volt (14s)
    Full Charge Voltage
    58.8
    Capacity (Amp-Hours)
    14.5
    Cell Type
    NCR21700A 14S x 3P
    Connector(s)
    Anderson, ST3
    52V 20Ah Downtube Battery
    Actual Weight (kg)
    5.38
    Dimensions (L x W x H, mm)
    370x89x137
    Mounting Type
    Frame Mount
    Nominal Voltage
    52 Volt (14s)
    Full Charge Voltage
    58.8
    Capacity (Amp-Hours)
    19.8
    Cell Type
    Panasonic GA 14S x 6P
    Internal Resistance (Ohms)
    0.12
    Connector(s)
    Anderson, ST3
    52V 23Ah Triangle Battery
    Actual Weight (kg)
    6.08
    Mounting Type
    Frame Mount
    Nominal Voltage
    52 Volt (14s)
    Full Charge Voltage
    58.8
    Capacity (Amp-Hours)
    23.5
    Cell Type
    Samsung 35E cells 14S x 7P
    Connector(s)
    Anderson, ST3, XT-90S
    36V 2A ST3 Charger
    Actual Weight (kg)
    0.36
    Connector(s)
    ST3
    36V 4A ST3 Charger 220VAC
    Actual Weight (kg)
    0.58
    Connector(s)
    ST3
    36V 2A XLR Charger
    Actual Weight (kg)
    0.5
    Connector(s)
    XLR
    36V 4A XLR Charger
    Actual Weight (kg)
    0.98
    Connector(s)
    XLR
    48V 2A ST3 Charger
    Actual Weight (kg)
    0.48
    Connector(s)
    ST3
    48V 4A ST3 Charger
    Actual Weight (kg)
    0.48
    Connector(s)
    ST3
    48V 2A XLR Charger
    Actual Weight (kg)
    0.5
    Connector(s)
    XLR
    52V 2A ST3 Charger
    Actual Weight (kg)
    .36
    Dimensions (L x W x H, mm)
    170x72x34
    Connector(s)
    ST3
    52V 2A XLR Charger
    Actual Weight (kg)
    0.5
    Dimensions (L x W x H, mm)
    170x72x34
    Connector(s)
    XLR
    52V 4A XLR Charger
    Actual Weight (kg)
    0.88
    Dimensions (L x W x H, mm)
    170x72x34
    Connector(s)
    XLR
    52V 4A ST-3 Charger 110-240
    Actual Weight (kg)
    0.84
    Connector(s)
    ST3
    Satiator Upgrade with ST3 Adapter
    Actual Weight (kg)
    1.06
    V5 Baserunner_Z9
    Manufacturer
    Grin
    Dimensions (L x W x H, mm)
    90 x 55 x 15
    Actual Weight (kg)
    0.18
    Max Regen Voltage (V)
    60
    Max Battery Amps (A)
    30
    Max Phase Amps (A)
    55
    Battery Range (V)
    20-60
    Connector(s)
    HiGo 0812(WP8), TRRS, Z910, HiGo MiniB, Mains D1109
    CA3-WPx
    Actual Weight (kg)
    0.3
    12 Pole PAS with Spindle Mounted Magdisc
    Manufacturer
    King Meter
    Actual Weight (kg)
    0.12
    PAS Poles
    12
    PAS Encoder Type
    2 Wire (Quadrature)
    12 Pole PAS with Chainring Mounted Magdisc
    PAS Poles
    12
    PAS Encoder Type
    2 Wire (Quadrature)
    24 Pole PAS (Short 90cm Cable)
    Actual Weight (kg)
    .06
    Connector(s)
    JST-SM
    PAS Poles
    24
    PAS Encoder Type
    2 Wire (Quadrature)
    24 Pole PAS (Long 120cm Cable)
    Actual Weight (kg)
    .06
    Connector(s)
    JST-SM
    PAS Poles
    24
    PAS Encoder Type
    2 Wire (Quadrature)
    Fischer AG Torque Sensing BB, 127mm
    Actual Weight (kg)
    0.3300
    Connector(s)
    JST-SM, HiGo MiniB
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    0.6
    ERider68-T17 BB with 4 Arm Spider
    Actual Weight (kg)
    1.06
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    ERider68-T17 BB with 5 Arm Spider
    Actual Weight (kg)
    1.06
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    ERider68-T17 BB with 52T Chainring
    Actual Weight (kg)
    1.3
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    ERider73-T17 BB with 4 Arm Spider
    Actual Weight (kg)
    1.06
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    ERider73-T17 BB with 5 Arm Spider
    Actual Weight (kg)
    1.06
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    ERider73-T17 BB with 52T Chainring
    Actual Weight (kg)
    1.3
    Connector(s)
    Higo Signal C, JST-SM
    PAS Poles
    18
    PAS Encoder Type
    2 Wire (Quadrature)
    Torque Sensor Offset Voltage
    1.5V
    Handlebar Phone Mount and Charger
    Actual Weight (kg)
    0.165
    Minimum Input Voltage (V)
    12
    Max Input Voltage (V)
    95
    Connector / Jack
    5.5 x 2.1mm DC Jack
    Output Voltage
    5V
    Output Current (A)
    2
    C7 Plus, 3W 80 Lux Ebike Light
    Actual Weight (kg)
    .088
    Light Source
    OSRAM
    Minimum Input Voltage (V)
    6
    Max Input Voltage (V)
    58
    Peak Input Power (Watts)
    3
    Connector / Jack
    DC5.5x2.1
    Roxim X4 Ebike Light
    Actual Weight (kg)
    0.16
    Light Source
    Cree XP-L
    Lumens Output
    400
    Minimum Input Voltage (V)
    6
    Max Input Voltage (V)
    85
    Peak Input Power (Watts)
    5.5
    Connector / Jack
    DC 5.5x2.1mm
    SPL-01 1900 Lumen Ebike Light
    Actual Weight (kg)
    0.12
    Light Source
    Multiple LEDs
    Lumens Output
    1900
    Turn-On Voltage (reduced power)
    8
    Minimum Input Voltage (V)
    12
    Max Input Voltage (V)
    60
    Peak Input Power (Watts)
    20
    Connector / Jack
    DC 5.5x2.1mm
    More Information
    Product Attachments
    Cycle Analyst Version 3.1 User Manual, Rev1.2 (2.46 MB)
    SX2 Motor Dimensional Diagram (98.75 kB)
    Phaserunner V3 Updates (538.75 kB)
    Phaserunner User Manual V2 (1.45 MB)
    SX2 Motor Dimensional Diagram (98.75 kB)
    SX2 Motor Dimensional Diagram (98.75 kB)
    Battery_Care_Guide (162.81 kB)
    Battery Care Guide - Japanese(translated by a happy customer in Japan) (117.72 kB)
    Battery_Care_Guide (162.81 kB)
    Battery Care Guide - Japanese(translated by a happy customer in Japan) (117.72 kB)
    Battery_Care_Guide (162.81 kB)
    Battery Care Guide - Japanese(translated by a happy customer in Japan) (117.72 kB)
    eZee 36V 15Ah Lithium Battery Manual (395.21 kB)
    Battery_Care_Guide (162.81 kB)
    Battery_Care_Guide (162.81 kB)
    Battery Care Guide - Japanese(translated by a happy customer in Japan) (117.72 kB)
    Battery_Care_Guide (162.81 kB)
    Battery Care Guide - Japanese(translated by a happy customer in Japan) (117.72 kB)
    Battery_Care_Guide (162.81 kB)
    Battery Care Guide - Japanese(translated by a happy customer in Japan) (117.72 kB)
    eZee 48V 10Ah Lithium Battery with Sony Konion Cells Manual (400.56 kB)
    Battery Care Guide - Japanese(translated by a happy customer in Japan) (117.72 kB)
    Battery_Care_Guide (162.81 kB)
    Satiator User Manual for 1.0X Firmware (1.20 MB)
    Cycle Analyst Version 3.1 User Manual, Rev1.2 (2.46 MB)
    12 Pole PAS Specifications and Installation Guide (462.79 kB)
    12 Pole PAS Specifications and Installation Guide (462.79 kB)
    24 Pole PAS Specifications and Installation Guide (468.83 kB)
    24 Pole PAS Specifications and Installation Guide (468.83 kB)
    FAGTorqueSensingBBManual-Grin (281.79 kB)
    T17Manual (896.13 kB)
    T17Manual_1 (896.13 kB)
    T17Manual (896.13 kB)
    T17Manual (896.13 kB)
    TripWire Pull Specifications (426.56 kB)
    TripWire Push Short Specifications (425.65 kB)
    Torque Arm V4 Installation and Specifications (473.60 kB)
    TA_V5_Manual_rev0 (894.44 kB)
    TA_V6_Manual_rev0 (905.60 kB)
    Roxim Front Light Specifications (410.92 kB)
    USB->TTL Programming Cable Manual (1.33 MB)
