My Fat Trek, created for comfort
Yuma, Arizona
|
137
Published: 2023-08-27
I had some extra stuff in the bike workshop, Alpha Trek frame, Jones handlebars, Surlly fork and 24" BMX rims. The result is a lowered balloon tire comfy bike with great balance and power using the Ezee rear motor and controller. Add a CA3 with a PAS wheel for a carefree comfortable ride with an upright posture. With this build, I tried to create a bike with some striking looks. The red, black and white worked well together.
The Build List for the Fat Trek
Fat Trek E-Bike
Component List:
Trek 4900 Alpha Frame - Aluminum
Jones Handlebar
Ergon Grips
XLC Stem
Shimano Revo-Shift 7-Speed
Surly Front Fork - steel
ISM Seat - Cruise model
Hope Adjustable Seat post Clamp
Topeak Rear Rack System
Metropolis Crankset and Chain guard
40T Sinz Chain ring
Ergon Platform Pedals
Shimano Deore XT Front Hub
Alienation 24" BMX Aluminum Welded Rims - front & rear
13 Gage Sapin SS Black Spokes - front & rear
Thick Brick 24"x3" Whitewall Ballon Tires - front & rear
Avid Disk Brakes - front & rear
205mm Disk Brake Rotors - front & rear
Ezee Rear Geared Hub Motor - 750 watts (legal limit)
Ezee Controller matched to motor
PAS Wheel on Crankset for Pedal Mode
Throttle with 3 position option switch on handlebar
Cycle Analyst V3 control display with stem mount
Maryvale Left-side rear mirror
