Grin Front All-Axle Hub, Fast Wind
From
USD$590.00
To
USD$925.00
Regular Price
USD$944.20
Add to Wish List
Add to Compare
Custom build of a fast wind Grin All-Axle hub motor with lacing options into your choice of rim. This 12 rpm/V motor winding is typically used for 16" and 20" wheel builds, especially those running with lower voltage battery packs like 36".
The latest V3 motor model has a stronger axle with a 16mm bore which provides more room for cable clearance and should be selected by default.
More Information
No selected items have relevant specifications
V3 Front All-Axle, Fst Black
Country of Manufacture
Canada
Motor Power Range (Watts)
500-1000
Phase Resistance (Ohm)
0.10
Disk Brake Compatible
Yes
Thermistor Style
10K NTC, Beta ~3450
Flange Spoke Diameter (mm)
214
Magnetic Pole Pairs (Phaserunner)
23
Hysteresis Losses (N-m)
0.6
Eddie Losses (N-m / rad/sec)
0.005
Motor Inductance (H)
0.0003
V3 Front All-Axle, Fst Silver
Country of Manufacture
Canada
Motor Power Range (Watts)
500-1000
Phase Resistance (Ohm)
0.10
Disk Brake Compatible
Yes
Thermistor Style
10K NTC, Beta ~3450
Flange Spoke Diameter (mm)
214
Magnetic Pole Pairs (Phaserunner)
23
Hysteresis Losses (N-m)
0.6
Eddie Losses (N-m / rad/sec)
0.005
Motor Inductance (H)
0.0003
V2 Front All-Axle, Fst Black
Country of Manufacture
Canada
Motor Power Range (Watts)
500-1000
Phase Resistance (Ohm)
0.10
Disk Brake Compatible
Yes
Thermistor Style
10K NTC, B~3900
Flange Spoke Diameter (mm)
214
Magnetic Pole Pairs (Phaserunner)
23
Hysteresis Losses (N-m)
0.6
Eddie Losses (N-m / rad/sec)
0.005
Motor Inductance (H)
0.0003
V2 Front All-Axle, Fst Silver
Country of Manufacture
Canada
Motor Power Range (Watts)
500-1000
Phase Resistance (Ohm)
0.10
Disk Brake Compatible
Yes
Thermistor Style
10K NTC, B~3900
Flange Spoke Diameter (mm)
214
Magnetic Pole Pairs (Phaserunner)
23
Hysteresis Losses (N-m)
0.6
Eddie Losses (N-m / rad/sec)
0.005
Motor Inductance (H)
0.0003
Rim16_ZAC19_32H
Nominal Rim Size
16" (ISO 349)
Valve Type
Presta, Schrader
Rim20_ZAC19_32H
Nominal Rim Size
20" (ISO 406)
Valve Type
Presta, Schrader
Rim20_DM18_32H
Country of Manufacture
China
Nominal Rim Size
20" (ISO 406)
Rim20_DM30_32H
Nominal Rim Size
20" (ISO 406)
Rim20_Alex_32H
Country of Manufacture
China
Nominal Rim Size
20" (ISO 406)
Rim ID in Spoke Calculator
20DM
Rim20_Fat_32H
Country of Manufacture
China
Nominal Rim Size
20" (ISO 406)
Rim ID in Spoke Calculator
20FAT
Rim20_Fat90_32H
Country of Manufacture
China
Nominal Rim Size
20" (ISO 406)
Rim ID in Spoke Calculator
20FAT90
Rim24_Alex_32H
Country of Manufacture
China
Nominal Rim Size
24" (ISO 507)
Rim ID in Spoke Calculator
24DM
Rim24_DM30_32H
Country of Manufacture
China
Nominal Rim Size
24" (ISO 507)
Rim ID in Spoke Calculator
24DM30
Rim24_Fat_32H
Country of Manufacture
China
Nominal Rim Size
24" (ISO 507)
Rim ID in Spoke Calculator
24FAT
Rim26_DM18_32H
Country of Manufacture
Taiwan
Nominal Rim Size
26" (ISO 559)
Rim ID in Spoke Calculator
26DM18
Rim26_Alex_32H
Country of Manufacture
Taiwan
Nominal Rim Size
26" (ISO 559)
Rim ID in Spoke Calculator
26DM
Rim26_Fat_32H
Country of Manufacture
China
Nominal Rim Size
26" (ISO 559)
Rim ID in Spoke Calculator
26FAT
Rim26_Fat80_32H
Nominal Rim Size
26" (ISO 559)
Rim ID in Spoke Calculator
26FAT80
Rim275_DM30_32H
Country of Manufacture
China
Nominal Rim Size
650B (ISO 584)
Rim ID in Spoke Calculator
650DM
Rim700_DM18_32H
Country of Manufacture
China
Nominal Rim Size
700C (ISO 622)
Rim ID in Spoke Calculator
700DM18
Rim700_Alex_32H
Country of Manufacture
China
Nominal Rim Size
700C (ISO 622)
Rim ID in Spoke Calculator
700DM
Rim700_MD23_32H
Country of Manufacture
China
Nominal Rim Size
700C (ISO 622)
Labour for Hand Lacing Grin Supplied Hub Motor Into a Grin Supplied Rim
Click Here for detailed product info page
Laser Engrave 250 Watt Continuous Power Rating on Motor Side Plate. This is Truthful. ALL Hub Motors Offered by Grin Have an Operating Point (RPM and Allowable Temperature) Where They Can Only Sustain 250W.
Click Here for detailed product info page
Magura Storm HC 160mm 6-Bolt Rotor
Click Here for detailed product info page
CNC Machined Torque Arm and Frame Clamp Assembly for the Front All-Axle Hub Motor
Click Here for detailed product info page
16" Fractional ( ETRTO349) ZAC19 Weinmann Rim with 32 Holes. For Brompton and Some Recumbent Bikes. Larger Than Typical 16" Kids Size.
Click Here for detailed product info page
Custom Cut Silver Sapim Strong Spoke, Butted 13-14 Gauge, Includes Nipple
Click Here for detailed product info page
Magura 180mm 6-Bolt Rotor
Click Here for detailed product info page
20" ZAC19 Weinmann Rim with eyelets, 24mm Wide, 32h
Click Here for detailed product info page
Custom Cut Black Sapim Spokes, Butted 13-14 Gauge, Includes Nipple
Click Here for detailed product info page
Magura 203mm 6-Bolt Rotor
Click Here for detailed product info page
20" DM18 Alex Rim, 32 Hole for Grin All Axle Hub, 24mm Wide with Eyelets
Click Here for detailed product info page
- Out of Stock -
V3 Grin All-Axle Hub Motor. Black Side Plate. Fast 5 turn (~12.0 rpm/V) Winding.
Click Here for detailed product info page
V3 Grin All-Axle Hub Motor. Silver. Fast 5 turn (~12.0 rpm/V) Winding.
Click Here for detailed product info page
V3 Front All-Axle Adapters for Standard Quick Release Skewers
Click Here for detailed product info page
20" DM30 Weinmann Double Wall Black 30mm Wide, 32 holes
Click Here for detailed product info page
- Out of Stock -
Grin All-Axle Hub Motor. Black Side Plate. Fast 5 turn (~12.0 rpm/V) Winding.
Click Here for detailed product info page
V3 Front All-Axle Adapters for 12mm Thru-Axle Forks
Click Here for detailed product info page
20" DM24 Alex Rim, 32 hole for Gin All Axle Hub, 32mm Wide with Stainless Steel Spoke Eyelets
Click Here for detailed product info page
Grin All-Axle Hub Motor. Silver. Fast 5 turn (~12.0 rpm/V) Winding.
Click Here for detailed product info page
V3 Front All-Axle Adapters for 15mm Thru-Axle Forks
Click Here for detailed product info page
20 Inch, 32 Hole, 65mm Wide Weinmann Double Walled Rim, for Fat Bike Tires.
Click Here for detailed product info page
V3 Front All-Axle Adapters for 15mm Boost Size (110mm) Thru-Axle Forks. Adds 5mm to Each End of Axle for Same Dishing as 100mm Hub.
Click Here for detailed product info page
20" Blizzerk90 Fatbike Rim for 4.5-5" Tires. 32 Holes for Fat All-Axle Motor Wheelbuilds.
Click Here for detailed product info page
V3 Front All-Axle Adapters for 135mm fatbike forks with slotted dropouts
Click Here for detailed product info page
24" DM24 Alex Rim, 32 Hole for Grin All Axle Hub, 32mm Wide with Stainless Steel Spoke Eyelets
Click Here for detailed product info page
V3 Front All-Axle Adapters for 15mm x 150mm Thru Axle Fatbike Forks.
Click Here for detailed product info page
24" DM30 Weinmann Double Wall Black/ Silver 30mm Wide Rim
Click Here for detailed product info page
V2 Front All-Axle Adapters for 20mm Thru-Axle Forks
Click Here for detailed product info page
24 Inch, 32 hole, 65mm Wide Weinmann Double Walled Rim, for Fat Bike Tires
Click Here for detailed product info page
26" DM18 Alex Rim, 24mm Wide, 32 Hole for Grin All Axle Hub, Black with Eyelets
Click Here for detailed product info page
26" DM24 Alex Rim Black, 32 Hole for Grin All Axle Hub, 32mm Wide with Stainless Steel Spoke Eyelets.
Click Here for detailed product info page
26 Inch, 32 hole, 65mm Wide Weinmann Double Walled Rim, for Fat Bike Tires.
Click Here for detailed product info page
26 Inch Blizzerk Rim, 80mm Wide, 32 Hole, for Fat Bike Motors
Click Here for detailed product info page
27.5" 650B DM30 Weinmann Double Wall Black/ Silver 30mm Wide Rim, 32 hole
Click Here for detailed product info page
700c (29") DM18 Alex Rim, 24mm Wide, 32 Hole for Grin All Axle Hub
Click Here for detailed product info page
700c (29") DM24 Alex Rim, 32 Hole for Grin All Axle Hub, 32mm Wide with Stainless Steel Spoke Eyelets
Click Here for detailed product info page
700c (29") MD23 Alex Rim, 32 hole for Grin All Axle Hub, 28mm Wide with Stainless Steel Spoke Eyelets. Disk brake only
Click Here for detailed product info page
- Out of Stock -
