Grin Rear V3 All-Axle Hub Build
Custom Wheelbuild of a Rear Grin All-Axle Hub Motor.
From
USD$635.00
To
USD$1,094.00
Regular Price
USD$1,113.20
Add to Wish List
Add to Compare
The V3 rear All-Axle motor from Grin has all the features you love about our front hub, ie a powerful, versatile, lightweight direct drive motor, but now available for the rear! As you would expect, this device is compatible with both thru-axle dropouts and quick release dropouts via swappable inserts.
Features
Compatible with 135mm, 145mm, and 160mm quick release dropouts
Compatible with 142mm, 148mm (boost), and 157mm (superboost) thru-axle dropouts
as integrated torque arm for zero dropout stress
Shimano HG or SRAM XD compatible freehub options
Integrated torque AND PAS sensor in freehub body
Statorade compatible for maximum heat dissipation
Lightest direct drive motor in this power class (just 4.25kg)
Internal 10K NTC thermistor for motor temperature sensing
More Information
No selected items have relevant specifications
V3 Rear All-Axle, Fst PAS
Country of Manufacture
Canada
Motor Power Range (Watts)
500-1000
Phase Resistance (Ohm)
0.11
Disk Brake Compatible
Yes
Connector(s)
L1019, Higo MiniB
Thermistor Style
10K NTC, Beta ~3450
Flange Spoke Diameter (mm)
214
Magnetic Pole Pairs (Phaserunner)
23
Hysteresis Losses (N-m)
0.6
Eddie Losses (N-m / rad/sec)
0.005
V3 Rear All-Axle, Std PAS
Country of Manufacture
Canada
Motor Power Range (Watts)
500-1000
Phase Resistance (Ohm)
0.145
Disk Brake Compatible
Yes
Connector(s)
L1019, Higo MiniB
Thermistor Style
10K NTC, Beta ~3450
Flange Spoke Diameter (mm)
214
Magnetic Pole Pairs (Phaserunner)
23
Hysteresis Losses (N-m)
0.6
Eddie Losses (N-m / rad/sec)
0.005
Motor Inductance (H)
0.0006
V3 Rear All-Axle, Slw PAS
Country of Manufacture
Canada
Motor Power Range (Watts)
500-1000
Phase Resistance (Ohm)
0.250
Disk Brake Compatible
Yes
Connector(s)
L1019, Higo MiniB
Thermistor Style
10K NTC, Beta ~3450
Flange Spoke Diameter (mm)
214
Magnetic Pole Pairs (Phaserunner)
23
Hysteresis Losses (N-m)
0.6
Eddie Losses (N-m / rad/sec)
0.005
V3 Rear All-Axle, Fst HG
Country of Manufacture
Canada
Motor Power Range (Watts)
500-1000
Phase Resistance (Ohm)
0.11
Disk Brake Compatible
Yes
Connector(s)
L1019, Higo MiniB
Thermistor Style
10K NTC, Beta ~3450
Flange Spoke Diameter (mm)
214
Magnetic Pole Pairs (Phaserunner)
23
Hysteresis Losses (N-m)
0.6
Eddie Losses (N-m / rad/sec)
0.005
V3 Rear All-Axle, Std HG
Country of Manufacture
Canada
Motor Power Range (Watts)
500-1000
Phase Resistance (Ohm)
0.145
Disk Brake Compatible
Yes
Thermistor Style
10K NTC, Beta ~3450
Flange Spoke Diameter (mm)
214
Magnetic Pole Pairs (Phaserunner)
23
Hysteresis Losses (N-m)
0.6
Eddie Losses (N-m / rad/sec)
0.005
Motor Inductance (H)
0.0006
V3 Rear All-Axle, Slw HG
Country of Manufacture
Canada
Motor Power Range (Watts)
500-1000
Phase Resistance (Ohm)
0.250
Disk Brake Compatible
Yes
Thermistor Style
10K NTC, Beta ~3450
Flange Spoke Diameter (mm)
214
Magnetic Pole Pairs (Phaserunner)
23
Hysteresis Losses (N-m)
0.6
Eddie Losses (N-m / rad/sec)
0.005
V3 Rear All-Axle, Fst XDR
Country of Manufacture
Canada
Motor Power Range (Watts)
500-1000
Phase Resistance (Ohm)
0.11
Disk Brake Compatible
Yes
Thermistor Style
10K NTC, Beta ~3450
Flange Spoke Diameter (mm)
214
Magnetic Pole Pairs (Phaserunner)
23
Hysteresis Losses (N-m)
0.6
Eddie Losses (N-m / rad/sec)
0.005
V3 Rear All-Axle, Slw XDR
Country of Manufacture
Canada
Motor Power Range (Watts)
500-1000
Phase Resistance (Ohm)
0.250
Disk Brake Compatible
Yes
Thermistor Style
10K NTC, Beta ~3450
Flange Spoke Diameter (mm)
214
Magnetic Pole Pairs (Phaserunner)
23
Hysteresis Losses (N-m)
0.6
Eddie Losses (N-m / rad/sec)
0.005
V3 Rear All-Axle, Std XDR
Country of Manufacture
Canada
Motor Power Range (Watts)
500-1000
Phase Resistance (Ohm)
0.145
Disk Brake Compatible
Yes
Thermistor Style
10K NTC, Beta ~3450
Flange Spoke Diameter (mm)
214
Magnetic Pole Pairs (Phaserunner)
23
Hysteresis Losses (N-m)
0.6
Eddie Losses (N-m / rad/sec)
0.005
Motor Inductance (H)
0.0006
Rim16_ZAC19_32H
Nominal Rim Size
16" (ISO 349)
Valve Type
Presta, Schrader
Rim20_ZAC19_32H
Nominal Rim Size
20" (ISO 406)
Valve Type
Presta, Schrader
Rim20_DM18_32H
Country of Manufacture
China
Nominal Rim Size
20" (ISO 406)
Rim20_DM30_32H
Nominal Rim Size
20" (ISO 406)
Rim20_Alex_32H
Country of Manufacture
China
Nominal Rim Size
20" (ISO 406)
Rim ID in Spoke Calculator
20DM
Rim20_Fat_32H
Country of Manufacture
China
Nominal Rim Size
20" (ISO 406)
Rim ID in Spoke Calculator
20FAT
Rim20_Fat90_32H
Country of Manufacture
China
Nominal Rim Size
20" (ISO 406)
Rim ID in Spoke Calculator
20FAT90
Rim24_Alex_32H
Country of Manufacture
China
Nominal Rim Size
24" (ISO 507)
Rim ID in Spoke Calculator
24DM
Rim24_DM30_32H
Country of Manufacture
China
Nominal Rim Size
24" (ISO 507)
Rim ID in Spoke Calculator
24DM30
Rim24_Fat_32H
Country of Manufacture
China
Nominal Rim Size
24" (ISO 507)
Rim ID in Spoke Calculator
24FAT
Rim26_DM18_32H
Country of Manufacture
Taiwan
Nominal Rim Size
26" (ISO 559)
Rim ID in Spoke Calculator
26DM18
Rim26_Alex_32H
Country of Manufacture
Taiwan
Nominal Rim Size
26" (ISO 559)
Rim ID in Spoke Calculator
26DM
Rim26_Fat_32H
Country of Manufacture
China
Nominal Rim Size
26" (ISO 559)
Rim ID in Spoke Calculator
26FAT
Rim26_Fat80_32H
Nominal Rim Size
26" (ISO 559)
Rim ID in Spoke Calculator
26FAT80
Rim275_DM30_32H
Country of Manufacture
China
Nominal Rim Size
650B (ISO 584)
Rim ID in Spoke Calculator
650DM
Rim700_DM18_32H
Country of Manufacture
China
Nominal Rim Size
700C (ISO 622)
Rim ID in Spoke Calculator
700DM18
Rim700_Alex_32H
Country of Manufacture
China
Nominal Rim Size
700C (ISO 622)
Rim ID in Spoke Calculator
700DM
Rim700_MD23_32H
Country of Manufacture
China
Nominal Rim Size
700C (ISO 622)
Labour for Hand Lacing Hub Motor Into Rim
Laser Engrave 250 Watt Continuous Power Rating on Motor Side Plate. This is Truthful. ALL Hub Motors Offered by Grin Have an Operating Point (RPM and Allowable Temperature) Where They Can Only Sustain 250W.
Click Here for detailed product info page
PAS/Torque Sensor to CA3 cable - HiGo 6 pin Female and 5-pin JST-SM Male, 120cm.
Click Here for detailed product info page
V3 Rear Grin All-Axle Hub Motor with built-in PAS sensor. Black. Fast 5 turn (~12 rpm/V) Winding. Shimano HG Freehub.
Click Here for detailed product info page
Magura Storm HC 160mm 6-Bolt Rotor
Click Here for detailed product info page
16" ( ETRTO349) ZAC19 Weinmann Rim with Eyelets, 25mm Wide, 32 holes
Click Here for detailed product info page
Custom Cut Silver Sapim Strong Spoke, Butted 13-14 Gauge, Includes Nipple
Click Here for detailed product info page
PAS/Torque Sensor to CA3 cable - HiGo 6 pin Female and 5-pin JST-SM Male, 70cm.
Click Here for detailed product info page
V3 Rear All-Axle Hub Motor with PAS Only Sensor. Black. Standard 6 Turn (~10 rpm/V) Winding. Shimano HG Freehub.
Click Here for detailed product info page
Magura 180mm 6-Bolt Rotor
Click Here for detailed product info page
CNC Machined Torque Arm and Frame Clamp Assembly for V3 Rear All Axle Hub Motor (Not Compatible with V2 Hubs)
Click Here for detailed product info page
20" ZAC19 Weinmann Rim with eyelets, 24mm Wide, 32h
Click Here for detailed product info page
Custom Cut Black Sapim Spokes, Butted 13-14 Gauge, Includes Nipple
Click Here for detailed product info page
24cm Long Extension Cable with 6 Pin HiGo MiniB Compatible Connectors, for Optional use with our Superharness
Click Here for detailed product info page
V3 Rear All-Axle Hub Motor with PAS Only Sensor. Black. Slow 8 turn (~7.5 rpm/V) Winding. Shimano HG Freehub.
Click Here for detailed product info page
V3 Rear All-Axle Motor Adapters for Standard 135mm (QR) Slotted Dropout
Click Here for detailed product info page
Magura 203mm 6-Bolt Rotor
Click Here for detailed product info page
20" DM18 Alex Rim, 32 Hole for Grin All Axle Hub, 24mm Wide with Eyelets
Click Here for detailed product info page
- Out of Stock -
44cm Long Extension Cable with 6 Pin HiGo MiniB Compatible Connectors, for Optional use with our Superharness
Click Here for detailed product info page
V3 Torque Sensing Rear All-Axle Hub Motor. Black. Fast 5 turn (~12 rpm/V) Winding. Shimano HG Freehub.
Click Here for detailed product info page
V3 Rear All-Axle Adapters for 142x12 Thru Axle Frames
Click Here for detailed product info page
1m Long Extension Cable with 6 Pin HiGo MiniB Compatible Connectors, for Optional use with Baserunner V4
Click Here for detailed product info page
- Out of Stock -
V3 Torque Sensing Rear All-Axle Hub Motor. Black. Standard 6 Turn (~10 rpm/V) Winding. Shimano HG Freehub.
Click Here for detailed product info page
V3 All-Axle Rear Adapters for Tandem Bikes with 145mm Dropout Spacing
Click Here for detailed product info page
20" DM30 Weinmann Double Wall Black 30mm Wide, 32 holes
Click Here for detailed product info page
- Out of Stock -
V3 Torque Sensing Rear All-Axle Hub Motor. Black. Slow 8 turn (~7.5 rpm/V) Winding. Shimano HG Freehub.
Click Here for detailed product info page
V3 All-Axle Rear Adapters for 148x12 Thru Axle Frames
Click Here for detailed product info page
20" DM24 Alex Rim, 32 hole for Gin All Axle Hub, 32mm Wide with Stainless Steel Spoke Eyelets
Click Here for detailed product info page
V3 Torque Sensing Rear All-Axle Hub Motor. Black. Fast 5 turn (~12 rpm/V) Winding. SRAM XDR Driver.
Click Here for detailed product info page
V3 All-Axle Rear Adapters for 157x12 Superboost Thru-Axle Dropouts
Click Here for detailed product info page
20 Inch, 32 Hole, 65mm Wide Weinmann Double Walled Rim, for Fat Bike Tires.
Click Here for detailed product info page
V3 Torque Sensing Rear All-Axle Hub Motor. Black. Slow 8 turn (~7.5 rpm/V) Winding. SRAM XDR Driver.
Click Here for detailed product info page
V3 All-Axle Rear Adapters for 160mm Slotted Dropouts/167mm Thru' Axle in Santana Tandem Bicycles
Click Here for detailed product info page
20" Blizzerk90 Fatbike Rim for 4.5-5" Tires. 32 Holes for Fat All-Axle Motor Wheelbuilds.
Click Here for detailed product info page
V3 Torque Sensing Rear All-Axle Hub Motor. Black. Standard 6 Turn (~10 rpm/V) Winding. SRAM XDR Driver.
Click Here for detailed product info page
24" DM24 Alex Rim, 32 Hole for Grin All Axle Hub, 32mm Wide with Stainless Steel Spoke Eyelets
Click Here for detailed product info page
24" DM30 Weinmann Double Wall Black/ Silver 30mm Wide Rim
Click Here for detailed product info page
24 Inch, 32 hole, 65mm Wide Weinmann Double Walled Rim, for Fat Bike Tires
Click Here for detailed product info page
26" DM18 Alex Rim, 24mm Wide, 32 Hole for Grin All Axle Hub, Black with Eyelets
Click Here for detailed product info page
26" DM24 Alex Rim Black, 32 Hole for Grin All Axle Hub, 32mm Wide with Stainless Steel Spoke Eyelets.
Click Here for detailed product info page
26 Inch, 32 hole, 65mm Wide Weinmann Double Walled Rim, for Fat Bike Tires.
Click Here for detailed product info page
26 Inch Blizzerk Rim, 80mm Wide, 32 Hole, for Fat Bike Motors
Click Here for detailed product info page
27.5" 650B DM30 Weinmann Double Wall Black/ Silver 30mm Wide Rim, 32 hole
Click Here for detailed product info page
700c (29") DM18 Alex Rim, 24mm Wide, 32 Hole for Grin All Axle Hub
Click Here for detailed product info page
700c (29") DM24 Alex Rim, 32 Hole for Grin All Axle Hub, 32mm Wide with Stainless Steel Spoke Eyelets
Click Here for detailed product info page
700c (29") MD23 Alex Rim, 32 hole for Grin All Axle Hub, 28mm Wide with Stainless Steel Spoke Eyelets. Disk brake only
Click Here for detailed product info page
- Out of Stock -
Canadian
