Crystalyte Rear Thru Axle, High Voltage Kit

Rear Crystalyte Thru Axle Kit with a V3 Cycle Analyst and PAS/ Sensor Options.

Out of stock

SKU
KIT-H_TA_HV
Customize Crystalyte Rear Thru Axle, High Voltage Kit
CA3-WPx
CA3_MFSwitch for CA3-WPx

* Required Fields

Your Customization
Crystalyte Rear Thru Axle, High Voltage Kit
Summary
    Rear Crystalyte H series motor kit for Thru Axle bike frames. Includes powerful direct drive rear hub motor laced in a double walled rim, a 7-9 speed freewheel, a 72V compatible regen capable controller, wiring accessories, a V3 Cycle Analyst, and your choice of PAS or torque sensor for pedelec modes. This is a one of the first rear kits on the market suitable for thru axle bike frames. Note however that it uses threaded freewheel instead of cassette freehub, and may require downgrading to a lower 7-9 speed shifter setup

    For a full explanation of the various drop-down choices and a comparison of this package versus other motor options, see our Grin Kits Info Page

    For details on the PAS/Torque sensor selection, see the Advanced PAS Kit Info Page
