Grin All-Axle, Minimal Kit

Front Grin All Axle Hub Motor Kit for Quick Release and Thru Axle Forks. Minimal Package with Throttle Control.

Full Product Information Page

The lead time for the All-Axle motors might be longer than usual due to the manufacturing infrastructure upgrade.

From USD$735.00 Regular Price USD$855.00

To USD$1,451.00

In stock

SKU
KIT-Grin_Min
Add to Wish List Add to Compare
Customize Grin All-Axle, Minimal Kit

* Required Fields

Your Customization
Grin All-Axle Motor Conversion Kit, Natural Silver
Grin All-Axle, Minimal Kit

In stock

USD$735.00

Actual cruising speed/perfomance under any loading conditions is well modeled in our simulator.
Launch Motor Simulator with Grin All-Axle, Minimal Kit

Summary

    Conversion kit based around the Grin All-Axle direct drive hub motor for basic throttle control without PAS. Supports quick release forks, 15mm x 100mm thru axle, and 20mm x 110mm thru axle systems. Same power as a 9C+ motor but 30 % lighter at only 4.0 kg. Includes integrated torque arm so there are no spreading forces on the dropouts.

    Specifications
    GrinHub_SL
    Actual Weight (kg)
    4.05
    Motor MFG
    Grin Tech
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    7.5
    Phase Resistance (Ohm)
    0.268
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Spoke Holes
    32 Hole
    Flange Spoke Diameter (mm)
    214
    Magnetic Pole Pairs (Phaserunner)
    23
    Hysteresis Losses (N-m)
    0.6
    Eddie Losses (N-m / rad/sec)
    0.005
    GrinHub_SL_Bk
    Actual Weight (kg)
    4.05
    Motor MFG
    Grin Tech
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    7.5
    Phase Resistance (Ohm)
    0.268
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Spoke Holes
    32 Hole
    Flange Spoke Diameter (mm)
    214
    Magnetic Pole Pairs (Phaserunner)
    23
    Hysteresis Losses (N-m)
    0.6
    Eddie Losses (N-m / rad/sec)
    0.005
    GrinHub_Std
    Actual Weight (kg)
    4.05
    Motor MFG
    Grin Tech
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    10.0
    Phase Resistance (Ohm)
    0.145
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Spoke Holes
    32 Hole
    Flange Spoke Diameter (mm)
    214
    Magnetic Pole Pairs (Phaserunner)
    23
    Hysteresis Losses (N-m)
    0.45
    Eddie Losses (N-m / rad/sec)
    0.005
    GrinHub_Std_Bk
    Actual Weight (kg)
    4.05
    Motor MFG
    Grin Tech
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    10.0
    Phase Resistance (Ohm)
    0.145
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Spoke Holes
    32 Hole
    Flange Spoke Diameter (mm)
    214
    Magnetic Pole Pairs (Phaserunner)
    23
    Hysteresis Losses (N-m)
    0.45
    Eddie Losses (N-m / rad/sec)
    0.005
    GrinHub_Fst
    Actual Weight (kg)
    4.05
    Motor MFG
    Grin Tech
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    12.0
    Phase Resistance (Ohm)
    0.10
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Spoke Holes
    32 Hole
    Flange Spoke Diameter (mm)
    214
    Magnetic Pole Pairs (Phaserunner)
    23
    Hysteresis Losses (N-m)
    0.45
    Eddie Losses (N-m / rad/sec)
    0.005
    GrinHub_Fst_Bk
    Actual Weight (kg)
    4.05
    Motor MFG
    Grin Tech
    Motor Power Range (Watts)
    500-1000
    Motor KV (RPM / V)
    12.0
    Phase Resistance (Ohm)
    0.10
    Disk Brake Compatible
    Yes
    Connector(s)
    L1019
    Thermistor Style
    10K NTC, Beta ~3900
    Axle Length (O.L.D.)
    100
    Spoke Holes
    32 Hole
    Flange Spoke Diameter (mm)
    214
    Magnetic Pole Pairs (Phaserunner)
    23
    Hysteresis Losses (N-m)
    0.45
    Eddie Losses (N-m / rad/sec)
    0.005
    Rim16_ZAC19_32H
    Actual Weight (kg)
    0.64
    Rim Width (mm)
    25
    Spoke Holes
    32 Hole
    Nominal Rim Size
    16" (ISO 349)
    Rim ERD
    332
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim20_ZAC19 32H
    Actual Weight (kg)
    0.42
    Rim Width (mm)
    24
    Spoke Holes
    32 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim ERD
    394
    Rim Brake Compatible
    Yes
    Valve Type
    Presta, Schrader
    Rim20_DM30 32h
    Rim Width (mm)
    30
    Spoke Holes
    32 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim Brake Compatible
    Yes
    Rim20_Fat_32H
    Actual Weight (kg)
    0.82
    Rim Width (mm)
    65
    Spoke Holes
    32 Hole
    Nominal Rim Size
    20" (ISO 406)
    Rim ERD
    384
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim24_Alex_32H
    Actual Weight (kg)
    0.64
    Rim Width (mm)
    32
    Spoke Holes
    32 Hole
    Nominal Rim Size
    24" (ISO 507)
    Rim ERD
    494
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim24_Fat_32H
    Actual Weight (kg)
    1.02
    Rim Width (mm)
    65
    Spoke Holes
    32 Hole
    Nominal Rim Size
    24" (ISO 507)
    Rim ERD
    485
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim26_DM18_32H
    Actual Weight (kg)
    0.53
    Rim Width (mm)
    24
    Spoke Holes
    32 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    543
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim26_Alex_32H
    Actual Weight (kg)
    0.76
    Rim Width (mm)
    32
    Spoke Holes
    32 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    544
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim26_Fat_32H
    Actual Weight (kg)
    1.06
    Rim Width (mm)
    65
    Spoke Holes
    32 Hole
    Nominal Rim Size
    26" (ISO 559)
    Rim ERD
    537
    Rim Brake Compatible
    No
    Valve Type
    Schrader
    Rim275_DM30_32H
    Actual Weight (kg)
    0.76
    Rim Width (mm)
    30
    Spoke Holes
    32 Hole
    Nominal Rim Size
    650B (ISO 584)
    Rim ERD
    565
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim275_Alex_32H
    Actual Weight (kg)
    0.76
    Rim Width (mm)
    32
    Spoke Holes
    32 Hole
    Nominal Rim Size
    650B (ISO 584)
    Rim ERD
    565
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    Rim700_DM18_32H
    Actual Weight (kg)
    0.6
    Rim Width (mm)
    24
    Spoke Holes
    32 Hole
    Nominal Rim Size
    700C (ISO 622)
    Rim ERD
    607
    Rim Brake Compatible
    Yes
    Valve Type
    Schrader
    V4 Baserunner_L10 (36V max)
    Manufacturer
    Grin
    Dimensions (L x W x H, mm)
    90 x 55 x 15
    Actual Weight (kg)
    0.18
    Max Battery Amps (A)
    35
    Max Phase Amps (A)
    70
    Battery Range (V)
    20-60
    Connector(s)
    HiGo 0812(WP8), Higo Signal C, L1019, TRRS
    V5 Baserunner_L10
    Manufacturer
    Grin
    Dimensions (L x W x H, mm)
    90 x 55 x 15
    Actual Weight (kg)
    0.18
    Max Regen Voltage (V)
    60
    Max Battery Amps (A)
    35
    Max Phase Amps (A)
    70
    Battery Range (V)
    20-60
    Connector(s)
    HiGo 0812(WP8), Higo Signal C, L1019, TRRS
    V6 Baserunner_L10
    Manufacturer
    Grin
    Dimensions (L x W x H, mm)
    90 x 55 x 15
    Actual Weight (kg)
    0.18
    Max Regen Voltage (V)
    60
    Max Battery Amps (A)
    35
    Max Phase Amps (A)
    80
    Battery Range (V)
    20-60
    Connector(s)
    HiGo 0812(WP8), Higo Signal C, Mains D1109
    Phaserunner L10 Silver
    Manufacturer
    Grin
    Dimensions (L x W x H, mm)
    99 x 40 x 34
    Actual Weight (kg)
    0.26
    Max Regen Voltage (V)
    Programmable: 20-90V
    Max Battery Amps (A)
    40
    Max Phase Amps (A)
    80
    Battery Range (V)
    30-90
    Connector(s)
    Anderson, HiGo 0812(WP8), L1019, TRRS, XT60, HiGo MiniB, Mains D1109
    Phaserunner L10 Black
    Manufacturer
    Grin
    Dimensions (L x W x H, mm)
    99 x 40 x 34
    Actual Weight (kg)
    0.26
    Max Regen Voltage (V)
    Programmable: 20-90V
    Max Battery Amps (A)
    40
    Max Phase Amps (A)
    90
    Battery Range (V)
    30-90
    Connector(s)
    Anderson, HiGo 0812(WP8), L1019, TRRS, XT60, HiGo MiniB, Mains D1109
    More Information
    Product Attachments
    Grin All-Axle Motor Dimensional Diagram (96.05 kB)
    Grin All-Axle Motor Dimensional Diagram (96.05 kB)
    Grin All-Axle Motor Dimensional Diagram (96.05 kB)
    Grin All-Axle Motor Dimensional Diagram (96.05 kB)
    Grin All-Axle Motor Dimensional Diagram (96.05 kB)
    Grin All-Axle Motor Dimensional Diagram (96.05 kB)
    3D IGS File of Grin SS DIY Adapter (622.05 kB)
    3D PDF File of Grin Single Side Adapters (136.59 kB)
    3D IGS File of Grin ICE Single Side Adapter (666.63 kB)
    3D PDF File of Grin Single Side Adapters (136.59 kB)
    3D IGS File of Grin Catrike Single Side Adapter (629.37 kB)
    3D PDF File of Grin Single Side Adapters (136.59 kB)
    3D IGS File of Grin Freecross Single Side Adapter (666.63 kB)
    3D PDF File of Grin Single Side Adapters (136.59 kB)
    3D IGS File of Grin Greenspeed Single Side Adapter (649.70 kB)
    3D PDF File of Grin Single Side Adapters (136.59 kB)
    3D IGS File of Grin Terratrike Single Side Adapter (651.36 kB)
    Phaserunner User Manual V2 (1.45 MB)
    V4_Baserunner_Manual_Draft (1.87 MB)
    V5 Baserunner_L10 Dimensional Diagram (44.22 kB)
    V5 Baserunner_L10 3D IGS File (497.93 kB)
    Phaserunner Dimensional Diagram (111.82 kB)
    Phaserunner User Manual V2 (1.45 MB)
    Phaserunner V3 Updates (538.75 kB)
    V6 Phaserunner Release Note (236.61 kB)
    Phaserunner V6 Manual (1.97 MB)
    V6 Phaserunner Release Note (236.61 kB)
    Phaserunner V6 Manual (1.97 MB)
    Phaserunner Dimensional Diagram (111.82 kB)
    Baserunner_Tube_Mount (39.22 kB)
    V4 Baserunner Manual (2.14 MB)
    TripWire Pull Specifications (426.56 kB)
    TripWire Push Short Specifications (425.65 kB)
    Statorade Specifications (44.44 kB)
    USB->TTL Programming Cable Manual (1.33 MB)
