More Information
No selected items have relevant specifications
7 Speed Cassette, 11-32 Tooth
Cluster Type
Freehub Cluster
8 Speed Cassette, 11-32 Tooth
Cluster Type
Freehub Cluster
9 Speed Cassette, 11-32 Tooth
Cluster Type
Freehub Cluster
10 Speed Cassette, 11-32 Tooth
Cluster Type
Freehub Cluster
Rim20_Fat
Nominal Rim Size
20" (ISO 406)
Rim24_Fat
Nominal Rim Size
24" (ISO 507)
Rim26_Fat
Nominal Rim Size
26" (ISO 559)
Rim26_Fat80
Nominal Rim Size
26" (ISO 559)
36V 10Ah Bottle Battery
Dimensions (L x W x H, mm)
295x78x78
Battery Mount Location
Frame Mount
Nominal Voltage
36 Volt (10s)
Watt-hours at 1C Discharge
345
Cell Type
Panasonic GA 10S x 4P
Internal Resistance (Ohms)
0.19
Connector(s)
Anderson, ST3
36V 14.5Ah Downtube Battery
Dimensions (L x W x H, mm)
365x100x105
Battery Mount Location
Frame Mount
Nominal Voltage
36 Volt (10s)
Capacity (Amp-Hours)
14.5
Cell Type
Samsung INR21700-50G 10S x 3P
Connector(s)
Anderson, DT_4pinSpade, ST3
36V 15.5Ah eZee Flat Pack
Dimensions (L x W x H, mm)
348x141x59
Battery Mount Location
Rear Rack
Nominal Voltage
36 Volt (10s)
Capacity (Amp-Hours)
15.5
Cell Type
LG 18650 MH1, 10S x 5P
Internal Resistance (Ohms)
0
Connector(s)
Anderson, XLR
36V 20Ah Downtube Battery
Dimensions (L x W x H, mm)
365x95x100
Battery Mount Location
Frame Mount
Nominal Voltage
36 Volt (10s)
Capacity (Amp-Hours)
19.25
Cell Type
Samsung INR21700-50G 10S x 4P
Connector(s)
Anderson, DT_4pinSpade, ST3
36V 22Ah eZee Flat Pack
Dimensions (L x W x H, mm)
348x141x59
Battery Mount Location
Rear Rack
Nominal Voltage
36 Volt (10s)
Capacity (Amp-Hours)
21.5
Cell Type
LG 18650 MH1, 10S x 7P
Internal Resistance (Ohms)
0
Connector(s)
Anderson, XLR
36V 24Ah Downtube Battery
Dimensions (L x W x H, mm)
365x95x124
Battery Mount Location
Frame Mount, Rear Rack
Nominal Voltage
36 Volt (10s)
Cell Type
Samsung INR21700-50G 10S x 5P
Internal Resistance (Ohms)
0.80
Connector(s)
Anderson, ST3
48V 14.5Ah Downtube Battery
Dimensions (L x W x H, mm)
365x100x105
Battery Mount Location
Frame Mount
Nominal Voltage
48 Volt (13s)
Cell Type
Samsung INR21700-50G 13S x 3P
Connector(s)
Anderson, DT_4pinSpade
48V 15.5Ah eZee Flat Pack
Dimensions (L x W x H, mm)
348x141x59
Battery Mount Location
Rear Rack
Nominal Voltage
48 Volt (13s)
Capacity (Amp-Hours)
15.5
Cell Type
LG 18650 MH1, 13S x 5P
Internal Resistance (Ohms)
0.156
Connector(s)
Anderson, XLR
48V 17Ah eZee Flat Pack
Dimensions (L x W x H, mm)
348x141x59
Battery Mount Location
Rear Rack
Nominal Voltage
48 Volt (13s)
Capacity (Amp-Hours)
16.5
Cell Type
Samsung 35E 13S x 5P
Internal Resistance (Ohms)
0.120
Connector(s)
Anderson, XLR
48V 19Ah Downtube Battery
Dimensions (L x W x H, mm)
365x100x124
Battery Mount Location
Frame Mount
Nominal Voltage
48 Volt (13s)
Cell Type
Samsung INR21700-50G 13S x 4P
Internal Resistance (Ohms)
0.12
Connector(s)
Anderson, ST3
52V 15Ah Downtube Battery
Dimensions (L x W x H, mm)
380x95x100
Battery Mount Location
Frame Mount
Nominal Voltage
52 Volt (14s)
Capacity (Amp-Hours)
14.5
Cell Type
NCR21700A 14S x 3P
Connector(s)
Anderson, ST3
52V 20Ah Downtube Battery
Dimensions (L x W x H, mm)
370x89x137
Battery Mount Location
Frame Mount
Nominal Voltage
52 Volt (14s)
Capacity (Amp-Hours)
19.8
Cell Type
Panasonic GA 14S x 6P
Internal Resistance (Ohms)
0.12
Connector(s)
Anderson, ST3
52V 23Ah Triangle Battery
Dimensions (L x W x H, mm)
350x400x230
Battery Mount Location
Frame Mount
Nominal Voltage
52 Volt (14s)
Capacity (Amp-Hours)
23.5
Cell Type
Panasonic GA 14S x 7P
Connector(s)
Anderson, ST3, XT-90S
52V 29Ah "Fuel tank" Battery
Dimensions (L x W x H, mm)
383x184x173
Battery Mount Location
Frame Mount
Nominal Voltage
52 Volt (14s)
Cell Type
Samsung INR21700-50G 14S x 6P
Internal Resistance (Ohms)
100
Connector(s)
Anderson, ST3
36V 2A ST3 Charger
Charge Port Connector
ST3
Charger Voltage
36V (42.0V max)
36V 2A XLR Charger
Charge Port Connector
3 Pin XLR
Charger Voltage
36V (42.0V max)
36V 4A XLR Charger
Charge Port Connector
3 Pin XLR
Charger Voltage
36V (42.0V max)
48V 4A ST3 Charger
Dimensions (L x W x H, mm)
197x82x46
Charge Port Connector
ST3
Charger Voltage
48V (54.6V max)
48V 2A ST3 Charger
Dimensions (L x W x H, mm)
169x71x40
Charge Port Connector
ST3
Charger Voltage
48V (54.6V max)
48V 2A XLR Charger
Charge Port Connector
3 Pin XLR
Charger Voltage
48V (54.6V max)
52V 2A ST3 Charger
Dimensions (L x W x H, mm)
170x72x34
Charge Port Connector
ST3
Charger Voltage
52V (58.8V max)
52V 2A XLR Charger
Dimensions (L x W x H, mm)
170x72x34
Charge Port Connector
3 Pin XLR
Charger Voltage
52V (58.8V max)
52V 4A XLR Charger
Dimensions (L x W x H, mm)
170x72x34
Charge Port Connector
3 Pin XLR
Charger Voltage
52V (58.8V max)
Satiator Upgrade with ST3 Adapter
12 Pole PAS with Spindle Mounted Magdisc
PAS Encoder Type
2 Wire (Quadrature)
12 Pole PAS with Chainring Mounted Magdisc
PAS Encoder Type
2 Wire (Quadrature)
24 Pole PAS (Short 90cm Cable)
PAS Encoder Type
2 Wire (Quadrature)
PAS_24P_Long
PAS Encoder Type
2 Wire (Quadrature)
Fischer AG Torque Sensing BB, 127mm
Actual Weight (kg)
0.3300
Connector(s)
JST-SM, HiGo MiniB
PAS Encoder Type
2 Wire (Quadrature)
Torque Sensor Offset Voltage
0.6
ERider68-T17 BB with 4 Arm Spider
Connector(s)
Higo Signal C, JST-SM
PAS Encoder Type
2 Wire (Quadrature)
Torque Sensor Offset Voltage
1.5V
ERider68-T17 BB with 5 Arm Spider
Connector(s)
Higo Signal C, JST-SM
PAS Encoder Type
2 Wire (Quadrature)
Torque Sensor Offset Voltage
1.5V
ERider68-T17 BB with 52T Chainring
Connector(s)
Higo Signal C, JST-SM
PAS Encoder Type
2 Wire (Quadrature)
Torque Sensor Offset Voltage
1.5V
ERider73-T17 BB with 4 Arm Spider
Connector(s)
Higo Signal C, JST-SM
PAS Encoder Type
2 Wire (Quadrature)
Torque Sensor Offset Voltage
1.5V
ERider73-T17 BB with 5 Arm Spider
Connector(s)
Higo Signal C, JST-SM
PAS Encoder Type
2 Wire (Quadrature)
Torque Sensor Offset Voltage
1.5V
ERider73-T17 BB with 52T Chainring
Connector(s)
Higo Signal C, JST-SM
PAS Encoder Type
2 Wire (Quadrature)
Torque Sensor Offset Voltage
1.5V
Handlebar Phone Mount and Charger
Minimum Input Voltage (V)
12
Connector / Jack
5.5 x 2.1mm DC Jack
C7 Plus, 3W 80 Lux Ebike Light
Minimum Input Voltage (V)
6
Peak Input Power (Watts)
3
Connector / Jack
DC5.5x2.1
SPL-01 1900 Lumen Ebike Light
Light Source
Multiple LEDs
Turn-On Voltage (reduced power)
8
Minimum Input Voltage (V)
12
Peak Input Power (Watts)
20
Connector / Jack
DC 5.5x2.1mm
Roxim Rear R1 ELight
Actual Weight (kg)
0.0690
Light Source
Red Cree XBD
Minimum Input Voltage (V)
6
Peak Input Power (Watts)
5.5
Connector / Jack
DC 5.5x2.1mm
Schwalbe Big Apple 26" Tire
Nominal Rim Size
26" (ISO 559)
