TSM-A5 Rear CA3 Kit

WINTER SALE - 30% Discount when Added to Cart!
Cycle Analyst Based Direct Drive Conversion Kit with Integrated Torque Sensor. TSM-A5 Motor, V3 Cycle Analyst, Baserunner L10, and Lithium Battery.

Full Product Information Page

Out of stock

SKU
KIT-TSM-A5_CA3
Customize TSM-A5 Rear CA3 Kit
Mounting Kit for TSM-A5 Motors
V5 Baserunner for Torque Sensing Motors
CA3-WPx
CA3_MFSwitch for CA3-WPx

* Required Fields

Your Customization
TSM-A5 Rear CA3 Kit
Summary

    This is a rear wheel conversion kit for the TSM-A5 direct drive hub motor, which has a built-in torque sensor from Innotorque on the freehub body, allowing for the construction of a torque controlled ebike without a torque sensing bottom bracket or dropout.

    • L1019 plug as Grin's other motors.
    • It has a torque signal and temperature signal on the two extra wires, rather than a wheel speed and temperature signal.
    • It is only compatible with specially modified versions of our Baserunner_L10 motor controller to take advantage of the internal torque sensor.
